Military
Insulated
Terminals

Filter
1125-46M-09518
1125-46M-09518
1125-46M-09518
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Gray M55155/108I02 AA59126/108I02
1125-42M-0514
1125-42M-0514
1125-42M-0514
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Yellow M55155/104H01 AA59126/104H01
1125-42M-0511
1125-42M-0511
1125-42M-0511
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Brown M55155/101H01 AA59126/101H01
1125-42M-09517
1125-42M-09517
1125-42M-09517
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Violet M55155/107I01 AA59126/107I01
1125-42M-09516
1125-42M-09516
1125-42M-09516
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Blue M55155/106I01 AA59126/106I01
1125-46M-08812
1125-46M-08812
1125-46M-08812
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Red M55155/102J02 AA59126/102J02
1125-42M-0512
1125-42M-0512
1125-42M-0512
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Red M55155/102H01 AA59126/102H01
1125-46M-0514
1125-46M-0514
1125-46M-0514
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Yellow M55155/104H02 AA59126/104H02
1125-46M-09511
1125-46M-09511
1125-46M-09511
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Brown M55155/101I02 AA59126/101I02
1125-42M-09515
1125-42M-09515
1125-42M-09515
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Green M55155/105I01 AA59126/105I01
1125-42M-08810
1125-42M-08810
1125-42M-08810
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Black M55155/100J01 AA59126/100J01
1125-42M-09514
1125-42M-09514
1125-42M-09514
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Yellow M55155/104I01 AA59126/104I01
1125-42M-09511
1125-42M-09511
1125-42M-09511
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Brown M55155/101I01 AA59126/101I01
1125-42M-08817
1125-42M-08817
1125-42M-08817
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Violet M55155/107J01 AA59126/107J01
1125-46M-0516
1125-46M-0516
1125-46M-0516
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Blue M55155/106H02 AA59126/106H02
1125-42M-0519
1125-42M-0519
1125-42M-0519
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE White M55155/109H01 AA59126/109H01
1125-46M-08813
1125-46M-08813
1125-46M-08813
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Orange M55155/103J02 AA59126/103J02
1114-08M-08813
1114-08M-08813
1114-08M-08813
0.310" - Press Fit 3/32 0.108 PTFE Orange M55155/053J02 AA59126/053J02
1114R-09M-0518
1114R-09M-0518
1114R-09M-0518
0.193" - Press Fit 1/32 0.113 PTFE Gray M55155/068H01 AA59126/068H01
1100-07M-08817Z
1100-07M-08817Z
1100-07M-08817Z
0.350" - Press Fit 1/16 0.086 PTFE Violet M55155/087D02 AA59126/087D02
