Non-Insulated
PC Jacks

Filter
09-9275-1-088
09-9275-1-088
09-9275-1-088
0.080 0.350 " 0.466" - - - - - Brass Bright Tin-Lead -
09-9217-1-03
09-9217-1-03
09-9217-1-03
0.040 0.175 " 0.305" Jack/Pin Solder - 1/32 - 1/16 0.056 Brass Gold Vertical
09-9260-1-03
09-9260-1-03
09-9260-1-03
0.060 - 0.062 0.142 " 0.213" - Press Fit/Solder - 1/16 - 3/32 0.102 Brass Gold Vertical
09-9101-1-03
09-9101-1-03
09-9101-1-03
0.080 0.333 " 0.412" - Press Fit/Solder - 1/16 - 1/4 0.151 (+0.001/-0.002) Brass Gold Vertical
09-9247-1-035
09-9247-1-035
09-9247-1-035
0.040 0.185 " 0.219" - Press Fit/Solder - 1/32 - 1/16 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9004-4-06
09-9004-4-06
09-9004-4-06
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9604-2-06
09-9604-2-06
09-9604-2-06
0.032 - 0.046 0.200 " 0.392" Jack/Turret Swage Mount 0.094" 1/16 0.094 Brass Electro-Tin Vertical
09-9670-2-03
09-9670-2-03
09-9670-2-03
0.015 - 0.025 0.146 " 0.219" - Swage Mount 0.084" 1/16 0.049 Brass Gold Vertical
09-9077-1-063
09-9077-1-063
09-9077-1-063
0.040 0.175 " 0.872" Jack/Square Wrap Pin Press Fit/Solder - 1/32 - 1/16 0.055 Brass Bright Tin-Lead Vertical
09-9077-1-035
09-9077-1-035
09-9077-1-035
0.040 0.175 " 0.872" Jack/Square Wrap Pin Press Fit/Solder - 1/32 - 1/16 0.055 Brass Gold Vertical
09-9004-3-035
09-9004-3-035
09-9004-3-035
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9066-1-063
09-9066-1-063
09-9066-1-063
0.022 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 5/32 0.055 Brass Bright Tin-Lead Vertical
09-9066-1-06
09-9066-1-06
09-9066-1-06
0.022 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 5/32 0.055 Brass Electro-Tin Vertical
09-9279-1-03
09-9279-1-03
09-9279-1-03
0.040 0.200 " 0.475" Jack/Turret Press Fit/Solder - 1/16 - 1/8 0.062 Brass Gold Vertical
09-9614-1-088
09-9614-1-088
09-9614-1-088
0.015 - 0.025 0.150 " 0.297" Jack/Pin Solder - 1/16 - 3/32 0.022 Brass Bright Tin-Lead Vertical
09-9614-1-063
09-9614-1-063
09-9614-1-063
0.015 - 0.025 0.150 " 0.297" Jack/Pin Solder - 1/16 - 3/32 0.022 Brass Bright Tin-Lead Vertical
09-9655-1-06
09-9655-1-06
09-9655-1-06
0.065 - 0.082 0.220 " 0.505" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.142 Brass Electro-Tin Vertical
09-9279-1-06
09-9279-1-06
09-9279-1-06
0.040 0.200 " 0.475" Jack/Turret Press Fit/Solder - 1/16 - 1/8 0.062 Brass Electro-Tin Vertical
09-9016-3-088
09-9016-3-088
09-9016-3-088
0.025 0.144 " 0.418" Jack/Pin Swage Mount 0.113" 3/32 0.062 Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
