Non-Insulated
PC Jacks

Filter
09-9666-1-035
09-9666-1-035
09-9666-1-035
0.015 - 0.025 0.126 " 0.146" - Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9172-1-06
09-9172-1-06
09-9172-1-06
0.014 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 3/32 - 3/16 0.055 Brass Electro-Tin Vertical
09-9677-1-06
09-9677-1-06
09-9677-1-06
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9711-1-088
09-9711-1-088
09-9711-1-088
0.016 - 0.020 0.126 " 0.138" - Solder - 1/32 - 3/32 0.043 Brass Bright Tin-Lead Vertical
09-9067-3-063
09-9067-3-063
09-9067-3-063
0.060 - 0.062 0.204 " 0.475" Jack/Turret Swage Mount 0.120" 3/32 0.144 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9609-1-063
09-9609-1-063
09-9609-1-063
0.015 - 0.025 0.150 " 0.343" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9081-1-063
09-9081-1-063
09-9081-1-063
0.040 0.190 " 0.511" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9610-1-063
09-9610-1-063
09-9610-1-063
0.015 - 0.025 0.150 " 0.356" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9172-1-063
09-9172-1-063
09-9172-1-063
0.014 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 3/32 - 3/16 0.055 Brass Bright Tin-Lead Vertical
09-9081-1-088
09-9081-1-088
09-9081-1-088
0.040 0.190 " 0.511" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9172-1-088
09-9172-1-088
09-9172-1-088
0.014 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 3/32 - 3/16 0.055 Brass Bright Tin-Lead Vertical
09-9666-1-063
09-9666-1-063
09-9666-1-063
0.015 - 0.025 0.126 " 0.146" - Press Fit/Solder - 1/16 - 3/32 0.057 Brass Bright Tin-Lead Vertical
09-9603-2-04
09-9603-2-04
09-9603-2-04
0.032 - 0.046 0.200 " 0.432" Jack/Slotted Swage Mount 0.094" 1/16 0.129 Brass Electro-Tin Vertical
09-9726-1-04
09-9726-1-04
09-9726-1-04
0.032 - 0.046 0.200 " 0.226" - Solder - 1/32 - 3/16 0.076 Brass Electro-Tin Vertical
09-9050-1-088
09-9050-1-088
09-9050-1-088
0.016 - 0.020 0.197 " 0.240" - Solder - 1/32 - 5/32 0.052 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9699-1-063
09-9699-1-063
09-9699-1-063
0.065 - 0.082 0.160 " 0.240" - Press Fit/Solder - 1/16 - 1/8 0.130 Brass Bright Tin-Lead Vertical
09-9006-1-035
09-9006-1-035
09-9006-1-035
0.040 0.185 " 0.220" - Solder - 1/32 - 1/8 0.076 Brass Gold Vertical
09-9711-1-06
09-9711-1-06
09-9711-1-06
0.016 - 0.020 0.126 " 0.138" - Solder - 1/32 - 3/32 0.043 Brass Electro-Tin Vertical
09-9050-1-063
09-9050-1-063
09-9050-1-063
0.016 - 0.020 0.197 " 0.240" - Solder - 1/32 - 5/32 0.052 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
