Non-Insulated
PC Jacks

Filter
09-9673-1-04
09-9673-1-04
09-9673-1-04
0.015 - 0.025 0.150 " 0.180" - Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9648-1-04
09-9648-1-04
09-9648-1-04
0.015 - 0.025 0.162 " 0.338" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.056 Brass Electro-Tin Vertical
09-9648-1-06
09-9648-1-06
09-9648-1-06
0.015 - 0.025 0.162 " 0.338" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.056 Brass Electro-Tin Vertical
09-9623-1-04
09-9623-1-04
09-9623-1-04
0.022 - 0.034 0.060 " 0.090" - Solder - 1/32 0.067 Brass Electro-Tin Vertical
09-9067-2-063
09-9067-2-063
09-9067-2-063
0.060 - 0.062 0.204 " 0.444" Jack/Turret Swage Mount 0.089" 1/16 0.144 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9260-1-06
09-9260-1-06
09-9260-1-06
0.060 - 0.062 0.142 " 0.213" - Press Fit/Solder - 1/16 - 3/32 0.102 Brass Electro-Tin Vertical
09-9650-1-088
09-9650-1-088
09-9650-1-088
0.015 - 0.025 0.205 " 0.248" Jack/Pin Solder - 1/32 - 5/32 0.052 Brass Bright Tin-Lead Vertical
09-9655-1-03
09-9655-1-03
09-9655-1-03
0.065 - 0.082 0.220 " 0.505" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.142 Brass Gold Vertical
09-9096-1-06
09-9096-1-06
09-9096-1-06
0.060 0.304 " 0.350" - Press Fit/Solder - 1/16 - 3/16 0.128 (+0.001/-0.002) Brass Electro-Tin Vertical
09-9728-1-063
09-9728-1-063
09-9728-1-063
0.032 - 0.046 0.137 " 0.206" - Solder - 1/32 - 5/32 0.076 Brass Bright Tin-Lead Vertical
09-9655-1-035
09-9655-1-035
09-9655-1-035
0.065 - 0.082 0.220 " 0.505" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.142 Brass Gold Vertical
09-9609-1-088
09-9609-1-088
09-9609-1-088
0.015 - 0.025 0.150 " 0.343" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9655-1-04
09-9655-1-04
09-9655-1-04
0.065 - 0.082 0.220 " 0.505" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.142 Brass Electro-Tin Vertical
09-9039-1-088
09-9039-1-088
09-9039-1-088
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Bright Tin-Lead Vertical
09-9727-1-063
09-9727-1-063
09-9727-1-063
0.032 - 0.046 0.241 " 0.270" - Solder - 1/32 - 3/16 0.075 Brass Bright Tin-Lead Vertical
09-9728-1-04
09-9728-1-04
09-9728-1-04
0.032 - 0.046 0.137 " 0.206" - Solder - 1/32 - 5/32 0.076 Brass Electro-Tin Vertical
09-9652-1-03
09-9652-1-03
09-9652-1-03
0.015 - 0.022 0.110 " 0.257" Jack/Pin Press Fit/Solder - 1/16 0.057 Brass Gold Vertical
09-9064-1-063
09-9064-1-063
09-9064-1-063
0.040 0.207 " 0.416" Jack/Pin Solder - 1/32 - 1/16 0.047 Brass Bright Tin-Lead Horizontal
09-6027-1-04
09-6027-1-04
09-6027-1-04
0.015 - 0.025 0.140 " 0.293" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.058 Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
