Non-Insulated
PC Jacks

Filter
09-9078-1-06
09-9078-1-06
09-9078-1-06
0.040 0.185 " 0.230" - Press Fit/Solder - 1/32 - 1/16 0.0995 (+0.001/-0.003) Brass Electro-Tin Vertical
09-9078-1-04
09-9078-1-04
09-9078-1-04
0.040 0.185 " 0.230" - Press Fit/Solder - 1/32 - 1/16 0.0995 (+0.001/-0.003) Brass Electro-Tin Vertical
09-9736-1-04
09-9736-1-04
09-9736-1-04
0.032 - 0.046 0.250 " 0.296" - Solder - 1/32 - 5/32 0.089 Brass Electro-Tin Vertical
09-9078-1-035
09-9078-1-035
09-9078-1-035
0.040 0.185 " 0.230" - Press Fit/Solder - 1/32 - 1/16 0.0995 (+0.001/-0.003) Brass Gold Vertical
09-9078-1-03
09-9078-1-03
09-9078-1-03
0.040 0.185 " 0.230" - Press Fit/Solder - 1/32 - 1/16 0.0995 (+0.001/-0.003) Brass Gold Vertical
09-9617-1-06
09-9617-1-06
09-9617-1-06
0.022 - 0.034 0.140 " 0.210" - Press Fit/Solder - 1/16 - 5/32 0.078 Brass Electro-Tin Vertical
09-9654-1-06
09-9654-1-06
09-9654-1-06
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9108-1-035
09-9108-1-035
09-9108-1-035
0.040 0.210 " 0.872" Jack/Square Wrap Pin Press Fit/Solder - 1/32 - 1/16 0.055 Brass Gold Vertical
09-9108-1-04
09-9108-1-04
09-9108-1-04
0.040 0.210 " 0.872" Jack/Square Wrap Pin Press Fit/Solder - 1/32 - 1/16 0.055 Brass Electro-Tin Vertical
09-9171-1-04
09-9171-1-04
09-9171-1-04
0.025 0.141 " 0.158" - Press Fit/Solder - 1/16 - 3/32 0.055 Brass Electro-Tin Vertical
09-9171-1-063
09-9171-1-063
09-9171-1-063
0.025 0.141 " 0.158" - Press Fit/Solder - 1/16 - 3/32 0.055 Brass Bright Tin-Lead Vertical
09-9613-1-063
09-9613-1-063
09-9613-1-063
0.015 - 0.025 0.148 " 0.173" - Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9172-1-04
09-9172-1-04
09-9172-1-04
0.014 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 3/32 - 3/16 0.055 Brass Electro-Tin Vertical
09-9093-1-03
09-9093-1-03
09-9093-1-03
0.022 0.207 " 0.235" - Solder - 1/32 - 5/32 0.052 (+0.002/-0.001) Brass Gold Vertical
09-9273-1-03
09-9273-1-03
09-9273-1-03
0.030 0.165 " 0.250" - Solder - 1/32 - 1/8 0.076 Brass Gold Vertical
09-9070-1-03
09-9070-1-03
09-9070-1-03
0.060 - 0.062 0.190 " 0.530" - - - - - Brass Gold -
09-9081-1-04
09-9081-1-04
09-9081-1-04
0.040 0.190 " 0.511" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.076 Brass Electro-Tin Vertical
09-9069-1-035
09-9069-1-035
09-9069-1-035
0.040 0.188 " 0.505" Jack/Edge Mount Screw Mount - - 0.063 (+0.003/-0.000) Brass Gold Horizontal
09-9648-1-035
09-9648-1-035
09-9648-1-035
0.015 - 0.025 0.162 " 0.338" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.056 Brass Gold Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
