Non-Insulated
PC Jacks

Filter
09-9262-1-03
09-9262-1-03
09-9262-1-03
0.040 0.220 " 0.375" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.083 Brass Gold Vertical
09-9262-1-04
09-9262-1-04
09-9262-1-04
0.040 0.220 " 0.375" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.083 Brass Electro-Tin Vertical
09-6019-1-035
09-6019-1-035
09-6019-1-035
0.015 - 0.025 0.140 " 0.553" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 3/32 0.058 Brass Gold Vertical
09-9022-6-063
09-9022-6-063
09-9022-6-063
0.025 0.393 " 0.437" Jack/Jack Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9603-4-04
09-9603-4-04
09-9603-4-04
0.032 - 0.046 0.200 " 0.432" Jack/Slotted Swage Mount 0.156" 1/8 0.129 Brass Electro-Tin Vertical
09-9739-1-088
09-9739-1-088
09-9739-1-088
0.032 - 0.046 0.205 " 0.385" Jack/Pin Press Fit/Solder - 3/32 - 3/16 0.090 Brass Bright Tin-Lead Vertical
09-9022-6-088
09-9022-6-088
09-9022-6-088
0.025 0.393 " 0.437" Jack/Jack Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9022-6-03
09-9022-6-03
09-9022-6-03
0.025 0.393 " 0.437" Jack/Jack Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9019-6-035
09-9019-6-035
09-9019-6-035
(0.025 & 0.040) 0.163 " 0.451" Jack/Jack Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9019-6-063
09-9019-6-063
09-9019-6-063
(0.025 & 0.040) 0.163 " 0.451" Jack/Jack Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9285-5-063
09-9285-5-063
09-9285-5-063
0.040 0.200 " 0.415" - Swage Mount 0.187" 5/32 0.067 Brass Bright Tin-Lead Vertical
09-9019-6-04
09-9019-6-04
09-9019-6-04
(0.025 & 0.040) 0.163 " 0.451" Jack/Jack Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9007-6-04
09-9007-6-04
09-9007-6-04
0.040 0.362 " 0.453" Jack/Jack Swage Mount 0.219" 3/16 0.129 Brass Electro-Tin Vertical
09-9638-1-03
09-9638-1-03
09-9638-1-03
0.025 - 0.037 0.230 " 0.490" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.062 Brass Gold Vertical
09-9291-1-03
09-9291-1-03
09-9291-1-03
0.040 0.207 " 0.416" Jack/Pin Solder - 1/64 0.046 Brass Gold Horizontal
09-9638-1-088
09-9638-1-088
09-9638-1-088
0.025 - 0.037 0.230 " 0.490" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.062 Brass Bright Tin-Lead Vertical
09-9625-1-035
09-9625-1-035
09-9625-1-035
0.022 - 0.034 0.170 " 0.200" - Press Fit/Solder - 1/16 - 5/32 0.067 Brass Gold Vertical
09-9625-1-06
09-9625-1-06
09-9625-1-06
0.022 - 0.034 0.170 " 0.200" - Press Fit/Solder - 1/16 - 5/32 0.067 Brass Electro-Tin Vertical
09-9625-1-063
09-9625-1-063
09-9625-1-063
0.022 - 0.034 0.170 " 0.200" - Press Fit/Solder - 1/16 - 5/32 0.067 Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
