Non-Insulated
PC Jacks

Filter
09-9019-2-04
09-9019-2-04
09-9019-2-04
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9019-2-03
09-9019-2-03
09-9019-2-03
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9022-4-063
09-9022-4-063
09-9022-4-063
0.025 0.336 " 0.374" Jack/Jack Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9022-4-06
09-9022-4-06
09-9022-4-06
0.025 0.336 " 0.374" Jack/Jack Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9619-1-088
09-9619-1-088
09-9619-1-088
0.022 - 0.034 0.210 " 0.250" - Solder - 1/32 - 3/32 0.072 Brass Bright Tin-Lead Vertical
09-9736-1-088
09-9736-1-088
09-9736-1-088
0.032 - 0.046 0.250 " 0.296" - Solder - 1/32 - 5/32 0.089 Brass Bright Tin-Lead Vertical
09-9291-1-063
09-9291-1-063
09-9291-1-063
0.040 0.207 " 0.416" Jack/Pin Solder - 1/64 0.046 Brass Bright Tin-Lead Horizontal
09-9626-2-063
09-9626-2-063
09-9626-2-063
0.025 - 0.037 0.180 " 0.397" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Bright Tin-Lead Vertical
09-9626-2-04
09-9626-2-04
09-9626-2-04
0.025 - 0.037 0.180 " 0.397" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Electro-Tin Vertical
09-9003-3-035
09-9003-3-035
09-9003-3-035
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.125" 3/32 0.129 Brass Gold Vertical
09-9003-3-06
09-9003-3-06
09-9003-3-06
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.125" 3/32 0.129 Brass Electro-Tin Vertical
09-9003-3-03
09-9003-3-03
09-9003-3-03
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.125" 3/32 0.129 Brass Gold Vertical
09-9003-4-088
09-9003-4-088
09-9003-4-088
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.156" 1/8 0.129 Brass Bright Tin-Lead Vertical
09-9662-1-035
09-9662-1-035
09-9662-1-035
0.015 - 0.021 0.055 " 0.083" - Solder - 1/32 0.041 Brass Gold Vertical
09-9662-1-04
09-9662-1-04
09-9662-1-04
0.015 - 0.021 0.055 " 0.083" - Solder - 1/32 0.041 Brass Electro-Tin Vertical
09-9662-1-063
09-9662-1-063
09-9662-1-063
0.015 - 0.021 0.055 " 0.083" - Solder - 1/32 0.041 Brass Bright Tin-Lead Vertical
09-9662-1-06
09-9662-1-06
09-9662-1-06
0.015 - 0.021 0.055 " 0.083" - Solder - 1/32 0.041 Brass Electro-Tin Vertical
09-9602-1-088
09-9602-1-088
09-9602-1-088
0.032 - 0.046 0.157 " 0.236" - Solder - 1/32 - 5/32 0.087 Brass Bright Tin-Lead Vertical
09-9626-1-06
09-9626-1-06
09-9626-1-06
0.025 - 0.037 0.180 " 0.320" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
