Non-Insulated
PC Jacks

Filter
09-9638-1-035
09-9638-1-035
09-9638-1-035
0.025 - 0.037 0.230 " 0.490" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.062 Brass Gold Vertical
09-9003-6-04
09-9003-6-04
09-9003-6-04
0.040 0.195 " 0.473" Jack/Slotted Swage Mount 0.219" 3/16 0.129 Brass Electro-Tin Vertical
09-9007-3-03
09-9007-3-03
09-9007-3-03
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.125" 3/32 0.129 Brass Gold Vertical
09-9007-3-04
09-9007-3-04
09-9007-3-04
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.125" 3/32 0.129 Brass Electro-Tin Vertical
09-9007-3-06
09-9007-3-06
09-9007-3-06
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.125" 3/32 0.129 Brass Electro-Tin Vertical
09-9007-2-03
09-9007-2-03
09-9007-2-03
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.094" 1/16 0.129 Brass Gold Vertical
09-9007-2-063
09-9007-2-063
09-9007-2-063
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.094" 1/16 0.129 Brass Bright Tin-Lead Vertical
09-9631-1-088
09-9631-1-088
09-9631-1-088
0.065 - 0.082 0.375 " 0.565" Jack/Pin Solder - 1/32 - 1/16 0.067 Brass Bright Tin-Lead Vertical
09-9066-1-04
09-9066-1-04
09-9066-1-04
0.022 0.225 " 0.880" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 5/32 0.055 Brass Electro-Tin Vertical
09-9034-1-035
09-9034-1-035
09-9034-1-035
0.030 - 0.032 0.190 " 0.206" - Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9007-4-088
09-9007-4-088
09-9007-4-088
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.156" 1/8 0.129 Brass Bright Tin-Lead Vertical
09-9652-1-04
09-9652-1-04
09-9652-1-04
0.015 - 0.022 0.110 " 0.257" Jack/Pin Press Fit/Solder - 1/16 0.057 Brass Electro-Tin Vertical
09-9019-3-04
09-9019-3-04
09-9019-3-04
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9660-1-088
09-9660-1-088
09-9660-1-088
0.015 - 0.025 0.147 " 0.296" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.059 Brass Bright Tin-Lead Vertical
09-9682-1-088
09-9682-1-088
09-9682-1-088
0.015 - 0.025 0.175 " 0.572" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.059 Brass Bright Tin-Lead Vertical
09-9682-1-03
09-9682-1-03
09-9682-1-03
0.015 - 0.025 0.175 " 0.572" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.059 Brass Gold Vertical
09-9019-3-035
09-9019-3-035
09-9019-3-035
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9019-3-03
09-9019-3-03
09-9019-3-03
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9019-2-063
09-9019-2-063
09-9019-2-063
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
