Non-Insulated
PC Jacks

Filter
09-9291-1-06
09-9291-1-06
09-9291-1-06
0.040 0.207 " 0.416" Jack/Pin Solder - 1/64 0.046 Brass Electro-Tin Horizontal
09-9003-2-088
09-9003-2-088
09-9003-2-088
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.094" 1/16 0.129 Brass Bright Tin-Lead Vertical
09-9638-2-088
09-9638-2-088
09-9638-2-088
0.025 - 0.037 0.230 " 0.440" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.062 Brass Bright Tin-Lead Vertical
09-9638-2-06
09-9638-2-06
09-9638-2-06
0.025 - 0.037 0.230 " 0.440" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.062 Brass Electro-Tin Vertical
09-9638-2-04
09-9638-2-04
09-9638-2-04
0.025 - 0.037 0.230 " 0.440" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.062 Brass Electro-Tin Vertical
09-9022-3-088
09-9022-3-088
09-9022-3-088
0.025 0.308 " 0.343" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9022-3-063
09-9022-3-063
09-9022-3-063
0.025 0.308 " 0.343" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9022-3-06
09-9022-3-06
09-9022-3-06
0.025 0.308 " 0.343" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9626-3-035
09-9626-3-035
09-9626-3-035
0.025 - 0.037 0.180 " 0.350" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Gold Vertical
09-9626-3-088
09-9626-3-088
09-9626-3-088
0.025 - 0.037 0.180 " 0.350" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Bright Tin-Lead Vertical
09-9289-1-04
09-9289-1-04
09-9289-1-04
0.040 0.207 " 0.416" Jack/Pin Solder - 1/32 - 1/16 0.046 Brass Electro-Tin Horizontal
09-9722-1-06
09-9722-1-06
09-9722-1-06
0.032 - 0.047 0.180 " 0.206" - Press Fit/Solder - 1/16 - 5/32 0.076 Brass Electro-Tin Vertical
09-9291-1-04
09-9291-1-04
09-9291-1-04
0.040 0.207 " 0.416" Jack/Pin Solder - 1/64 0.046 Brass Electro-Tin Horizontal
09-9722-1-035
09-9722-1-035
09-9722-1-035
0.032 - 0.047 0.180 " 0.206" - Press Fit/Solder - 1/16 - 5/32 0.076 Brass Gold Vertical
09-9626-3-063
09-9626-3-063
09-9626-3-063
0.025 - 0.037 0.180 " 0.350" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Bright Tin-Lead Vertical
09-9022-2-088
09-9022-2-088
09-9022-2-088
0.025 0.280 " 0.312" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9022-2-04
09-9022-2-04
09-9022-2-04
0.025 0.280 " 0.312" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9734-1-063
09-9734-1-063
09-9734-1-063
0.032 - 0.046 0.250 " 0.288" - Solder - 1/32 - 3/32 0.125 Brass Bright Tin-Lead Vertical
09-9022-2-06
09-9022-2-06
09-9022-2-06
0.025 0.280 " 0.312" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
