Non-Insulated
PC Jacks

09-9244-1-088
09-9244-1-088
09-9244-1-088
0.040 0.190 " 0.236" - Solder - 1/32 - 5/32 0.089 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9260-1-063
09-9260-1-063
09-9260-1-063
0.060 - 0.062 0.142 " 0.213" - Press Fit/Solder - 1/16 - 3/32 0.102 Brass Bright Tin-Lead Vertical
09-9647-1-063
09-9647-1-063
09-9647-1-063
0.032 - 0.046 0.155 " 0.233" - Solder - 1/32 - 5/32 0.104 Brass Bright Tin-Lead Vertical
09-9632-1-063
09-9632-1-063
09-9632-1-063
0.032 - 0.046 0.190 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Bright Tin-Lead Vertical
09-9670-3-035
09-9670-3-035
09-9670-3-035
0.015 - 0.025 0.166 " 0.250" - Swage Mount 0.115" 3/32 0.049 Brass Gold Vertical
09-9646-1-088
09-9646-1-088
09-9646-1-088
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Bright Tin-Lead Vertical
09-9646-1-063
09-9646-1-063
09-9646-1-063
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Bright Tin-Lead Vertical
09-9288-1-035
09-9288-1-035
09-9288-1-035
0.030 0.175 " 0.385" - - - - - Brass Gold -
09-9630-1-063
09-9630-1-063
09-9630-1-063
0.015 - 0.025 0.133 " 0.200" - Solder - 1/32 - 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9646-1-04
09-9646-1-04
09-9646-1-04
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Electro-Tin Vertical
09-9248-1-03
09-9248-1-03
09-9248-1-03
0.040 0.185 " 0.220" - Press Fit/Solder - 1/32 - 1/16 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9248-1-035
09-9248-1-035
09-9248-1-035
0.040 0.185 " 0.220" - Press Fit/Solder - 1/32 - 1/16 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9646-1-03
09-9646-1-03
09-9646-1-03
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Gold Vertical
09-9645-1-088
09-9645-1-088
09-9645-1-088
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Bright Tin-Lead Vertical
09-9645-1-06
09-9645-1-06
09-9645-1-06
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Electro-Tin Vertical
09-9744-1-088
09-9744-1-088
09-9744-1-088
0.032 - 0.046 0.300 " 0.800" Jack/Pin Solder - 1/32 - 3/8 0.082 Brass Bright Tin-Lead Vertical
09-9744-1-063
09-9744-1-063
09-9744-1-063
0.032 - 0.046 0.300 " 0.800" Jack/Pin Solder - 1/32 - 3/8 0.082 Brass Bright Tin-Lead Vertical
09-9744-1-06
09-9744-1-06
09-9744-1-06
0.032 - 0.046 0.300 " 0.800" Jack/Pin Solder - 1/32 - 3/8 0.082 Brass Electro-Tin Vertical
09-9744-1-035
09-9744-1-035
09-9744-1-035
0.032 - 0.046 0.300 " 0.800" Jack/Pin Solder - 1/32 - 3/8 0.082 Brass Gold Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
