Commercial
Non-Insulated
Terminals

Filter
10-512-8-044
10-512-8-044
10-512-8-044
0.661" - Double Turret/Double Turret Swage Mount 0.290" 1/4 0.129 Brass Bright Tin YES
09-0186-2-044
09-0186-2-044
09-0186-2-044
0.500" 0.018 SLOTTED/PIN Solder 0.080" 1/16 0.052 Brass Bright Tin YES
10-512-2-044
10-512-2-044
10-512-2-044
0.476" - Double Turret/Double Turret Swage Mount 0.105" 1/16 0.129 Brass Bright Tin YES
10-8015-4-044
10-8015-4-044
10-8015-4-044
0.520" 0.040 TURRET/PIN Swage Mount 0.145" 1/8 0.076 Brass Bright Tin YES
10-502-8-044
10-502-8-044
10-502-8-044
0.538" - TURRET/DOUBLE TURRET Swage Mount 0.270" 1/4 0.076 Brass Bright Tin YES
10-559-1-044
10-559-1-044
10-559-1-044
0.348" - TURRET/DOUBLE TURRET Swage Mount 0.053" 1/32 0.076 Brass Bright Tin YES
10-532-6-044
10-532-6-044
10-532-6-044
0.698" - Double Turret/Double Turret Swage Mount 0.230" 3/16 0.159 Brass Bright Tin YES
09-8623-1-044
09-8623-1-044
09-8623-1-044
0.398" 0.041 - Press Fit/Solder 0.045" 1/64 0.038 Brass Bright Tin YES
10-549-4-044
10-549-4-044
10-549-4-044
0.844" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.206 Brass Bright Tin YES
10-550-5-044
10-550-5-044
10-550-5-044
0.664" - TURRET/DOUBLE TURRET Swage Mount 0.195" 5/32 0.206 Brass Bright Tin YES
10-508-2-044
10-508-2-044
10-508-2-044
0.538" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Bright Tin YES
10-801-6-044
10-801-6-044
10-801-6-044
0.535" 0.040 TURRET/PIN Swage Mount 0.207" 3/16 0.076 Brass Bright Tin YES
09-0374-1-044
09-0374-1-044
09-0374-1-044
0.334" 0.025 TURRET/PIN Press Fit/Solder 0.080" 1/16 0.055 Brass Bright Tin YES
10-266-2-044
10-266-2-044
10-266-2-044
0.240" - - Swage Mount 0.084" 1/16 0.206 Brass Bright Tin YES
10-506-6-044
10-506-6-044
10-506-6-044
0.500" - Turret/Turret Swage Mount 0.219" 3/16 0.120 Brass Bright Tin YES
09-8699-1-044
09-8699-1-044
09-8699-1-044
0.578" 0.080 - Swage Mount 0.082" 1/16 0.086 Brass Bright Tin YES
10-101-4-044
10-101-4-044
10-101-4-044
0.249" - - Swage Mount 0.145" 1/8 0.076 Brass Bright Tin YES
10-8025-2-044
10-8025-2-044
10-8025-2-044
0.379" 0.040 TURRET/PIN Swage Mount 0.082" 1/16 0.076 Brass Bright Tin YES
09-0159-2-044
09-0159-2-044
09-0159-2-044
0.560" - Double Turret/Double Turret Solder 0.156" 1/32 TO 5/32 0.109 Brass Bright Tin YES
10-201-8-044
10-201-8-044
10-201-8-044
0.456" - - Swage Mount 0.270" 1/4 0.076 Brass Bright Tin YES
