Commercial
Non-Insulated
Terminals

Filter
14-346-4-05
14-346-4-05
14-346-4-05
0.360" - - Swage Mount 0.172" 1/8 0.082 LEADED Red Brass Electro Solder NO
09-8075-2-01
09-8075-2-01
09-8075-2-01
0.282" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
14-916-2-035
14-916-2-035
14-916-2-035
0.402" 0.040 - Swage Mount 0.082" 1/16 0.043 LEADED Red Brass Gold YES
10-137-2-044
10-137-2-044
10-137-2-044
0.268" - - Swage Mount 0.109" 1/16 0.094 Brass Bright Tin YES
09-8007-2-01
09-8007-2-01
09-8007-2-01
0.732" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
10-823-2-04
10-823-2-04
10-823-2-04
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro-Tin YES
10-512-1-03
10-512-1-03
10-512-1-03
0.446" - Double Turret/Double Turret Swage Mount 0.075" 1/32 0.129 Brass Gold YES
10-102-1-035
10-102-1-035
10-102-1-035
0.265" - - Swage Mount 0.078" 1/32 0.082 Brass Gold YES
10-201-2-04
10-201-2-04
10-201-2-04
0.268" - - Swage Mount 0.082" 1/16 0.076 Brass Electro-Tin YES
10-878-2-05
10-878-2-05
10-878-2-05
0.415" 0.040 Pin/Pin Swage Mount 0.082" 1/16 0.076 Brass Electro Solder NO
10-921-3-088
10-921-3-088
10-921-3-088
0.333" 0.045 - Swage Mount 0.125" 3/32 0.064 Brass Bright Tin-Lead NO
10-544-2-01
10-544-2-01
10-544-2-01
0.335" - Turret/Turret Swage Mount 0.094" 1/16 0.094 Brass Silver YES
09-0230-1-095
09-0230-1-095
09-0230-1-095
0.480" - - Swage Mount 0.055" 1/32 0.094 Brass Hot Solder Dip NO
10-803-6-04
10-803-6-04
10-803-6-04
0.582" 0.040 TURRET/PIN Swage Mount 0.207" 3/16 0.076 Brass Electro-Tin YES
10-805-2-095
10-805-2-095
10-805-2-095
0.399" - - Swage Mount 0.109" 1/16 0.094 Brass Hot Solder Dip NO
10-204-2-035
10-204-2-035
10-204-2-035
0.468" - - Swage Mount 0.109" 1/16 0.116 Brass Gold YES
09-8061-2-035
09-8061-2-035
09-8061-2-035
1.142" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
09-8298-4-04
09-8298-4-04
09-8298-4-04
0.338" 0.040 - Swage Mount 0.165" 1/8 0.076 Brass Electro-Tin YES
10-321-3-05
10-321-3-05
10-321-3-05
0.499" - Turret/Turret Swage Mount 0.125" 3/32 0.120 Brass Electro Solder NO
10-266-3-088
10-266-3-088
10-266-3-088
0.271" - - Swage Mount 0.115" 3/32 0.206 Brass Bright Tin-Lead NO
