Commercial
Non-Insulated
Terminals

Filter
10-315-2-088
10-315-2-088
10-315-2-088
0.433" - - Swage Mount 0.105" 1/16 0.082 Brass Bright Tin-Lead NO
10-544-3-05
10-544-3-05
10-544-3-05
0.366" - Turret/Turret Swage Mount 0.125" 3/32 0.094 Brass Electro Solder NO
10-544-3-035
10-544-3-035
10-544-3-035
0.366" - Turret/Turret Swage Mount 0.125" 3/32 0.094 Brass Gold YES
10-544-3-01
10-544-3-01
10-544-3-01
0.366" - Turret/Turret Swage Mount 0.125" 3/32 0.094 Brass Silver YES
10-137-3-01
10-137-3-01
10-137-3-01
0.300" - - Swage Mount 0.141" 3/32 0.094 Brass Silver YES
10-542-1-03
10-542-1-03
10-542-1-03
0.425" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.094 Brass Gold YES
10-542-2-04
10-542-2-04
10-542-2-04
0.457" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.094 Brass Electro-Tin YES
10-604-6-04
10-604-6-04
10-604-6-04
0.921" - - Swage Mount 0.234" 3/16 0.266 Brass Electro-Tin YES
09-8766-2-03
09-8766-2-03
09-8766-2-03
0.719" 0.090 - Swage Mount 0.094" 1/16 0.094 Brass Gold YES
09-0112-2-01
09-0112-2-01
09-0112-2-01
0.448" - TURRET/THREAD Swage Mount 0.094" 1/16 0.154 Brass Silver YES
10-940-2-04
10-940-2-04
10-940-2-04
0.282" - - Swage Mount 0.094" 1/16 0.0635 Brass Electro-Tin YES
09-0087-2-044
09-0087-2-044
09-0087-2-044
0.382" - SLOTTED/TURRET Solder 0.094" 1/16 0.096 Brass Bright Tin YES
09-0116-2-01
09-0116-2-01
09-0116-2-01
0.219" - - Swage Mount 0.094" 1/16 0.076 Brass Silver YES
10-862-2-03
10-862-2-03
10-862-2-03
0.344" 0.040 - Swage Mount 0.094" 1/16 0.094 Brass Gold YES
10-414-3-05
10-414-3-05
10-414-3-05
0.269" - - Swage Mount 0.113" 3/32 0.052 Brass Electro Solder NO
10-8008-3-05
10-8008-3-05
10-8008-3-05
0.525" 0.080 - Swage Mount 0.125" 3/32 0.094 Brass Electro Solder NO
10-806-6-05
10-806-6-05
10-806-6-05
0.661" - - Swage Mount 0.234" 3/16 0.094 Brass Electro Solder NO
10-807-8-05
10-807-8-05
10-807-8-05
0.640" - - Swage Mount 0.297" 1/4 0.094 Brass Electro Solder NO
10-806-2-05
10-806-2-05
10-806-2-05
0.536" - - Swage Mount 0.109" 1/16 0.094 Brass Electro Solder NO
10-606-1-05
10-606-1-05
10-606-1-05
0.391" - - Swage Mount 0.075" 1/32 0.094 Brass Electro Solder NO
