Commercial
Non-Insulated
Terminals

Filter
10-201-2-088
10-201-2-088
10-201-2-088
0.268" - - Swage Mount 0.082" 1/16 0.076 Brass Bright Tin-Lead NO
10-110-1-04
10-110-1-04
10-110-1-04
0.309" - - Swage Mount 0.075" 1/32 0.116 Brass Electro-Tin YES
09-8155-1-088
09-8155-1-088
09-8155-1-088
0.823" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin-Lead NO
10-509-5-088
10-509-5-088
10-509-5-088
0.852" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.204 Brass Bright Tin-Lead NO
09-0152-2-088
09-0152-2-088
09-0152-2-088
0.360" - - Swage Mount 0.090" 1/16 0.055 Brass Bright Tin-Lead NO
10-603-2-088
10-603-2-088
10-603-2-088
0.526" - - Swage Mount 0.105" 1/16 0.116 Brass Bright Tin-Lead NO
09-0271-1-088
09-0271-1-088
09-0271-1-088
0.130" 0.029 (+0.003/-0.001) - - 0.115" - - Brass Bright Tin-Lead NO
10-506-1-088
10-506-1-088
10-506-1-088
0.343" - Turret/Turret Swage Mount 0.062" 1/32 0.120 Brass Bright Tin-Lead NO
10-201-4-088
10-201-4-088
10-201-4-088
0.331" - - Swage Mount 0.145" 1/8 0.076 Brass Bright Tin-Lead NO
10-506-2-088
10-506-2-088
10-506-2-088
0.375" - Turret/Turret Swage Mount 0.094" 1/16 0.120 Brass Bright Tin-Lead NO
10-714-4-088
10-714-4-088
10-714-4-088
0.727" - DOUBLE TURRET/THREAD Swage Mount 0.165" 1/8 0.204 Brass Bright Tin-Lead NO
09-8171-2-088
09-8171-2-088
09-8171-2-088
0.924" 0.040 - Swage Mount 0.082" 1/16 0.076 Brass Bright Tin-Lead NO
10-201-1-088
10-201-1-088
10-201-1-088
0.237" - - Swage Mount 0.051" 1/32 0.076 Brass Bright Tin-Lead NO
10-603-1-088
10-603-1-088
10-603-1-088
0.496" - - Swage Mount 0.075" 1/32 0.116 Brass Bright Tin-Lead NO
10-576-4-088
10-576-4-088
10-576-4-088
0.446" - Turret/Turret Swage Mount 0.165" 1/8 0.120 Brass Bright Tin-Lead NO
10-522-6-088
10-522-6-088
10-522-6-088
0.699" - Turret/Turret Swage Mount 0.230" 3/16 0.206 Brass Bright Tin-Lead NO
09-8059-2-088
09-8059-2-088
09-8059-2-088
0.582" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Bright Tin-Lead NO
09-0112-2-088
09-0112-2-088
09-0112-2-088
0.448" - TURRET/THREAD Swage Mount 0.094" 1/16 0.154 Brass Bright Tin-Lead NO
