Non-Insulated
PC Jacks

Filter
09-9042-1-04
09-9042-1-04
09-9042-1-04
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-1-06
09-9042-1-06
09-9042-1-06
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-1-063
09-9042-1-063
09-9042-1-063
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-2-063
09-9042-2-063
09-9042-2-063
0.080 0.375 " 0.637" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-3-03
09-9042-3-03
09-9042-3-03
0.080 0.375 " 0.668" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9042-3-035
09-9042-3-035
09-9042-3-035
0.080 0.375 " 0.668" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9042-3-04
09-9042-3-04
09-9042-3-04
0.080 0.375 " 0.668" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-3-063
09-9042-3-063
09-9042-3-063
0.080 0.375 " 0.668" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-3-088
09-9042-3-088
09-9042-3-088
0.080 0.375 " 0.668" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-4-03
09-9042-4-03
09-9042-4-03
0.080 0.375 " 0.699" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9042-4-035
09-9042-4-035
09-9042-4-035
0.080 0.375 " 0.699" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9042-4-063
09-9042-4-063
09-9042-4-063
0.080 0.375 " 0.699" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-6-04
09-9042-6-04
09-9042-6-04
0.080 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-6-06
09-9042-6-06
09-9042-6-06
0.080 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-6-063
09-9042-6-063
09-9042-6-063
0.080 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9604-1-035
09-9604-1-035
09-9604-1-035
0.032 - 0.046 0.200 " 0.360" Jack/Turret Swage Mount 0.062" 1/32 0.094 Brass Gold Vertical
09-9604-1-04
09-9604-1-04
09-9604-1-04
0.032 - 0.046 0.200 " 0.360" Jack/Turret Swage Mount 0.062" 1/32 0.094 Brass Electro-Tin Vertical
09-9604-1-063
09-9604-1-063
09-9604-1-063
0.032 - 0.046 0.200 " 0.360" Jack/Turret Swage Mount 0.062" 1/32 0.094 Brass Bright Tin-Lead Vertical
09-9604-1-088
09-9604-1-088
09-9604-1-088
0.032 - 0.046 0.200 " 0.360" Jack/Turret Swage Mount 0.062" 1/32 0.094 Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
