Non-Insulated
PC Jacks

Filter
09-9745-1-063
09-9745-1-063
09-9745-1-063
0.032 - 0.046 0.495 " 0.630" Jack/Turret Press Fit/Solder - 1/16 - 3/8 0.0935 Brass Bright Tin-Lead Vertical
09-9686-1-063
09-9686-1-063
09-9686-1-063
0.025 - 0.037 0.240 " 0.394" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.061 Brass Bright Tin-Lead Vertical
09-9016-2-03
09-9016-2-03
09-9016-2-03
0.025 0.144 " 0.387" Jack/Pin Swage Mount 0.082" 1/16 0.062 Brass Gold Vertical
09-9686-1-088
09-9686-1-088
09-9686-1-088
0.025 - 0.037 0.240 " 0.394" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.061 Brass Bright Tin-Lead Vertical
09-9668-1-063
09-9668-1-063
09-9668-1-063
0.015 - 0.025 0.113 " 0.135" - Solder - 1/32 - 1/16 0.0625 Brass Bright Tin-Lead Vertical
09-9668-1-088
09-9668-1-088
09-9668-1-088
0.015 - 0.025 0.113 " 0.135" - Solder - 1/32 - 1/16 0.0625 Brass Bright Tin-Lead Vertical
09-9695-1-035
09-9695-1-035
09-9695-1-035
0.015 - 0.025 0.145 " 0.261" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9671-1-088
09-9671-1-088
09-9671-1-088
0.015 - 0.025 0.120 " 0.145" - Solder - 1/32 - 1/16 0.055 Brass Bright Tin-Lead Vertical
09-9671-1-04
09-9671-1-04
09-9671-1-04
0.015 - 0.025 0.120 " 0.145" - Solder - 1/32 - 1/16 0.055 Brass Electro-Tin Vertical
09-9743-1-06
09-9743-1-06
09-9743-1-06
0.032 - 0.046 0.210 " 0.260" - Press Fit/Solder - 1/16 - 5/32 0.073 Brass Electro-Tin Vertical
09-9685-1-03
09-9685-1-03
09-9685-1-03
0.025 - 0.037 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.061 Brass Gold Vertical
09-9685-1-035
09-9685-1-035
09-9685-1-035
0.025 - 0.037 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.061 Brass Gold Vertical
09-9016-1-035
09-9016-1-035
09-9016-1-035
0.025 0.144 " 0.356" Jack/Pin Swage Mount 0.051" 1/32 0.062 Brass Gold Vertical
09-9685-1-06
09-9685-1-06
09-9685-1-06
0.025 - 0.037 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.061 Brass Electro-Tin Vertical
09-9045-3-063
09-9045-3-063
09-9045-3-063
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9642-6-088
09-9642-6-088
09-9642-6-088
0.065 - 0.082 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.096 Brass Bright Tin-Lead Vertical
09-9045-6-04
09-9045-6-04
09-9045-6-04
0.025 0.141 " 0.397" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9045-6-035
09-9045-6-035
09-9045-6-035
0.025 0.141 " 0.397" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9045-4-088
09-9045-4-088
09-9045-4-088
0.025 0.141 " 0.334" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
