Non-Insulated
PC Jacks

Filter
09-9681-1-063
09-9681-1-063
09-9681-1-063
0.032 - 0.046 0.195 " 0.220" - Press Fit/Solder - 1/16 - 3/32 0.078 Brass Bright Tin-Lead Vertical
09-9735-1-03
09-9735-1-03
09-9735-1-03
0.032 - 0.046 0.106 " 0.160" - Press Fit/Solder - 1/16 - 3/32 0.090 Brass Gold Vertical
09-9007-6-03
09-9007-6-03
09-9007-6-03
0.040 0.362 " 0.453" Jack/Jack Swage Mount 0.219" 3/16 0.129 Brass Gold Vertical
09-9733-1-03
09-9733-1-03
09-9733-1-03
0.032 - 0.046 0.170 " 0.255" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Gold Vertical
09-9623-1-035
09-9623-1-035
09-9623-1-035
0.022 - 0.034 0.060 " 0.090" - Solder - 1/32 0.067 Brass Gold Vertical
09-9013-1-06
09-9013-1-06
09-9013-1-06
0.060 - 0.062 0.200 " 0.213" - Solder - 1/32 - 1/8 0.102 Brass Electro-Tin Vertical
09-9608-1-03
09-9608-1-03
09-9608-1-03
0.032 - 0.046 0.220 " 0.317" - Solder - 1/32 - 3/32 0.089 Brass Gold Vertical
09-9016-3-06
09-9016-3-06
09-9016-3-06
0.025 0.144 " 0.418" Jack/Pin Swage Mount 0.113" 3/32 0.062 Brass Electro-Tin Vertical
09-6019-1-088
09-6019-1-088
09-6019-1-088
0.015 - 0.025 0.140 " 0.553" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 3/32 0.058 Brass Bright Tin-Lead Vertical
09-9016-4-03
09-9016-4-03
09-9016-4-03
0.025 0.144 " 0.450" Jack/Pin Swage Mount 0.145" 1/8 0.062 Brass Gold Vertical
09-9016-4-035
09-9016-4-035
09-9016-4-035
0.025 0.144 " 0.450" Jack/Pin Swage Mount 0.145" 1/8 0.062 Brass Gold Vertical
09-9016-4-063
09-9016-4-063
09-9016-4-063
0.025 0.144 " 0.450" Jack/Pin Swage Mount 0.145" 1/8 0.062 Brass Bright Tin-Lead Vertical
09-9688-1-04
09-9688-1-04
09-9688-1-04
0.025 - 0.037 0.228 " 0.675" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.061 Brass Electro-Tin Vertical
09-9688-1-035
09-9688-1-035
09-9688-1-035
0.025 - 0.037 0.228 " 0.675" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.061 Brass Gold Vertical
09-9047-1-04
09-9047-1-04
09-9047-1-04
0.040 0.186 " 0.233" - Solder - 1/32 - 1/8 0.104 Brass Electro-Tin Vertical
09-9054-1-088
09-9054-1-088
09-9054-1-088
0.025 0.145 " 0.431" Jack/Pin Solder - 1/32 - 1/16 0.028 Brass Bright Tin-Lead Vertical
09-9056-1-088
09-9056-1-088
09-9056-1-088
0.040 0.185 " 0.530" - - - - - Brass Bright Tin-Lead -
09-9016-3-04
09-9016-3-04
09-9016-3-04
0.025 0.144 " 0.418" Jack/Pin Swage Mount 0.113" 3/32 0.062 Brass Electro-Tin Vertical
09-9061-1-06
09-9061-1-06
09-9061-1-06
0.050 0.200 " 0.213" - Solder - 1/32 - 5/32 0.102 Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
