Non-Insulated
PC Jacks

Filter
09-9178-1-088
09-9178-1-088
09-9178-1-088
0.040 0.187 " 0.270" - Solder - 1/32 - 3/16 0.073 Brass Bright Tin-Lead Vertical
09-9051-4-063
09-9051-4-063
09-9051-4-063
0.016 - 0.020 0.210 " 0.287" Jack/Turret Swage Mount 0.135" 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9602-1-035
09-9602-1-035
09-9602-1-035
0.032 - 0.046 0.157 " 0.236" - Solder - 1/32 - 5/32 0.087 Brass Gold Vertical
09-9275-1-035
09-9275-1-035
09-9275-1-035
0.080 0.350 " 0.466" - - - - - Brass Gold -
09-9197-1-088
09-9197-1-088
09-9197-1-088
0.080 0.325 " 0.797" Jack/Pin Solder - 1/32 - 3/32 0.083 Brass Bright Tin-Lead Vertical
09-9637-1-03
09-9637-1-03
09-9637-1-03
0.065 - 0.082 0.357 " 0.400" - Solder - 1/32 - 5/16 0.125 Brass Gold Vertical
09-9615-1-063
09-9615-1-063
09-9615-1-063
0.015 - 0.025 0.150 " 0.180" - Solder - 1/32 - 1/16 0.0635 Brass Bright Tin-Lead Vertical
09-9689-1-06
09-9689-1-06
09-9689-1-06
0.015 - 0.025 0.145 " 0.165" - Solder - 1/32 - 3/32 0.056 Brass Electro-Tin Vertical
09-9197-1-063
09-9197-1-063
09-9197-1-063
0.080 0.325 " 0.797" Jack/Pin Solder - 1/32 - 3/32 0.083 Brass Bright Tin-Lead Vertical
09-9069-1-04
09-9069-1-04
09-9069-1-04
0.040 0.188 " 0.505" Jack/Edge Mount Screw Mount - - 0.063 (+0.003/-0.000) Brass Electro-Tin Horizontal
09-9020-4-06
09-9020-4-06
09-9020-4-06
0.025 0.141 " 0.356" - Swage Mount 0.156" 1/8 0.062 Brass Electro-Tin Vertical
09-9630-1-06
09-9630-1-06
09-9630-1-06
0.015 - 0.025 0.133 " 0.200" - Solder - 1/32 - 1/8 0.076 Brass Electro-Tin Vertical
09-9005-6-035
09-9005-6-035
09-9005-6-035
0.040 0.190 " 0.606" Jack/Pin Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9656-1-06
09-9656-1-06
09-9656-1-06
0.032 - 0.046 0.200 " 0.530" - - - - - Brass Electro-Tin -
09-9648-1-063
09-9648-1-063
09-9648-1-063
0.015 - 0.025 0.162 " 0.338" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.056 Brass Bright Tin-Lead Vertical
09-9648-1-088
09-9648-1-088
09-9648-1-088
0.015 - 0.025 0.162 " 0.338" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.056 Brass Bright Tin-Lead Vertical
09-9051-4-04
09-9051-4-04
09-9051-4-04
0.016 - 0.020 0.210 " 0.287" Jack/Turret Swage Mount 0.135" 1/8 0.076 Brass Electro-Tin Vertical
09-9003-2-063
09-9003-2-063
09-9003-2-063
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.094" 1/16 0.129 Brass Bright Tin-Lead Vertical
09-9652-1-035
09-9652-1-035
09-9652-1-035
0.015 - 0.022 0.110 " 0.257" Jack/Pin Press Fit/Solder - 1/16 0.057 Brass Gold Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
