Non-Insulated
PC Jacks

Filter
09-9691-1-035
09-9691-1-035
09-9691-1-035
0.015 - 0.025 0.145 " 0.343" Jack/Pin Press Fit/Solder - 3/32 - 3/16 0.057 Brass Gold Vertical
09-9690-1-063
09-9690-1-063
09-9690-1-063
0.015 - 0.025 0.145 " 0.290" Jack/Pin Press Fit/Solder - 3/32 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9690-1-06
09-9690-1-06
09-9690-1-06
0.015 - 0.025 0.145 " 0.290" Jack/Pin Press Fit/Solder - 3/32 - 1/8 0.057 Brass Electro-Tin Vertical
09-9689-1-088
09-9689-1-088
09-9689-1-088
0.015 - 0.025 0.145 " 0.165" - Solder - 1/32 - 3/32 0.056 Brass Bright Tin-Lead Vertical
09-9689-1-063
09-9689-1-063
09-9689-1-063
0.015 - 0.025 0.145 " 0.165" - Solder - 1/32 - 3/32 0.056 Brass Bright Tin-Lead Vertical
09-9019-4-063
09-9019-4-063
09-9019-4-063
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9683-1-088
09-9683-1-088
09-9683-1-088
0.015 - 0.025 0.130 " 0.190" - Solder - 1/32 - 1/8 0.056 Brass Bright Tin-Lead Vertical
09-9683-1-03
09-9683-1-03
09-9683-1-03
0.015 - 0.025 0.130 " 0.190" - Solder - 1/32 - 1/8 0.056 Brass Gold Vertical
09-9680-1-088
09-9680-1-088
09-9680-1-088
0.015 - 0.025 0.162 " 0.203" - Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9680-1-063
09-9680-1-063
09-9680-1-063
0.015 - 0.025 0.162 " 0.203" - Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9680-1-035
09-9680-1-035
09-9680-1-035
0.015 - 0.025 0.162 " 0.203" - Press Fit/Solder - 1/16 - 1/8 0.057 Brass Gold Vertical
09-9679-1-063
09-9679-1-063
09-9679-1-063
0.015 - 0.025 0.146 " 0.317" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Bright Tin-Lead Vertical
09-9679-1-04
09-9679-1-04
09-9679-1-04
0.015 - 0.025 0.146 " 0.317" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9679-1-035
09-9679-1-035
09-9679-1-035
0.015 - 0.025 0.146 " 0.317" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9679-1-03
09-9679-1-03
09-9679-1-03
0.015 - 0.025 0.146 " 0.317" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9678-1-06
09-9678-1-06
09-9678-1-06
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 0.057 Brass Electro-Tin Vertical
09-9678-1-04
09-9678-1-04
09-9678-1-04
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 0.057 Brass Electro-Tin Vertical
09-9677-1-088
09-9677-1-088
09-9677-1-088
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Bright Tin-Lead Vertical
09-9677-1-035
09-9677-1-035
09-9677-1-035
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
