Non-Insulated
PC Jacks

Filter
09-9020-1-035
09-9020-1-035
09-9020-1-035
0.025 0.141 " 0.262" - Swage Mount 0.062" 1/32 0.062 Brass Gold Vertical
09-9732-1-03
09-9732-1-03
09-9732-1-03
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Gold Vertical
09-9031-1-04
09-9031-1-04
09-9031-1-04
0.030 - 0.032 0.185 " 0.250" - Press Fit/Solder - 1/16 - 3/16 0.089 Brass Electro-Tin Vertical
09-9681-1-06
09-9681-1-06
09-9681-1-06
0.032 - 0.046 0.195 " 0.220" - Press Fit/Solder - 1/16 - 3/32 0.078 Brass Electro-Tin Vertical
09-9733-1-063
09-9733-1-063
09-9733-1-063
0.032 - 0.046 0.170 " 0.255" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Bright Tin-Lead Vertical
09-9031-1-035
09-9031-1-035
09-9031-1-035
0.030 - 0.032 0.185 " 0.250" - Press Fit/Solder - 1/16 - 3/16 0.089 Brass Gold Vertical
09-9007-4-04
09-9007-4-04
09-9007-4-04
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.156" 1/8 0.129 Brass Electro-Tin Vertical
09-9681-1-04
09-9681-1-04
09-9681-1-04
0.032 - 0.046 0.195 " 0.220" - Press Fit/Solder - 1/16 - 3/32 0.078 Brass Electro-Tin Vertical
09-9007-2-04
09-9007-2-04
09-9007-2-04
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.094" 1/16 0.129 Brass Electro-Tin Vertical
09-9737-1-06
09-9737-1-06
09-9737-1-06
0.032 - 0.046 0.323 " 0.353" - Solder - 1/32 - 3/16 0.076 Brass Electro-Tin Vertical
09-9007-2-035
09-9007-2-035
09-9007-2-035
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.094" 1/16 0.129 Brass Gold Vertical
09-9120-1-03
09-9120-1-03
09-9120-1-03
0.060 - 0.062 0.109 " 0.530" - - - - - Brass Gold -
09-9037-3-088
09-9037-3-088
09-9037-3-088
0.030 - 0.032 0.183 " 0.421" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9037-3-063
09-9037-3-063
09-9037-3-063
0.030 - 0.032 0.183 " 0.421" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9008-1-03
09-9008-1-03
09-9008-1-03
0.040 0.192 " 0.317" - Solder - 1/32 - 3/32 0.089 Brass Gold Vertical
09-9037-3-03
09-9037-3-03
09-9037-3-03
0.030 - 0.032 0.183 " 0.421" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9031-1-03
09-9031-1-03
09-9031-1-03
0.030 - 0.032 0.185 " 0.250" - Press Fit/Solder - 1/16 - 3/16 0.089 Brass Gold Vertical
09-9007-4-063
09-9007-4-063
09-9007-4-063
0.040 0.325 " 0.406" Jack/Jack Swage Mount 0.156" 1/8 0.129 Brass Bright Tin-Lead Vertical
09-9037-2-063
09-9037-2-063
09-9037-2-063
0.030 - 0.032 0.183 " 0.390" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
