Non-Insulated
PC Jacks

Filter
09-9654-1-03
09-9654-1-03
09-9654-1-03
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9003-4-063
09-9003-4-063
09-9003-4-063
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.156" 1/8 0.129 Brass Bright Tin-Lead Vertical
09-9005-6-03
09-9005-6-03
09-9005-6-03
0.040 0.190 " 0.606" Jack/Pin Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9003-3-063
09-9003-3-063
09-9003-3-063
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.125" 3/32 0.129 Brass Bright Tin-Lead Vertical
09-9051-4-06
09-9051-4-06
09-9051-4-06
0.016 - 0.020 0.210 " 0.287" Jack/Turret Swage Mount 0.135" 1/8 0.076 Brass Electro-Tin Vertical
09-9654-1-035
09-9654-1-035
09-9654-1-035
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9053-1-035
09-9053-1-035
09-9053-1-035
0.040 0.185 " 0.240" Jack/Turret Press Fit/Solder - 1/32 - 5/32 0.076 Brass Gold Vertical
09-9003-3-04
09-9003-3-04
09-9003-3-04
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.125" 3/32 0.129 Brass Electro-Tin Vertical
09-9619-1-04
09-9619-1-04
09-9619-1-04
0.022 - 0.034 0.210 " 0.250" - Solder - 1/32 - 3/32 0.072 Brass Electro-Tin Vertical
09-9237-1-06
09-9237-1-06
09-9237-1-06
0.030 0.110 " 0.424" Jack/Pin Solder - 1/32 - 3/32 0.072 Brass Electro-Tin Vertical
09-9016-2-063
09-9016-2-063
09-9016-2-063
0.025 0.144 " 0.387" Jack/Pin Swage Mount 0.082" 1/16 0.062 Brass Bright Tin-Lead Vertical
09-9622-1-035
09-9622-1-035
09-9622-1-035
0.022 - 0.034 0.120 " 0.180" - Solder - 1/32 0.067 Brass Gold Vertical
09-9687-1-04
09-9687-1-04
09-9687-1-04
0.025 - 0.037 0.228 " 0.486" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.061 Brass Electro-Tin Vertical
09-9101-1-06
09-9101-1-06
09-9101-1-06
0.080 0.333 " 0.412" - Press Fit/Solder - 1/16 - 1/4 0.151 (+0.001/-0.002) Brass Electro-Tin Vertical
09-9020-4-03
09-9020-4-03
09-9020-4-03
0.025 0.141 " 0.356" - Swage Mount 0.156" 1/8 0.062 Brass Gold Vertical
09-9020-2-088
09-9020-2-088
09-9020-2-088
0.025 0.141 " 0.294" - Swage Mount 0.094" 1/16 0.062 Brass Bright Tin-Lead Vertical
09-9058-1-035
09-9058-1-035
09-9058-1-035
0.025 0.185 " 0.504" - - - - - Brass Gold -
09-9120-1-035
09-9120-1-035
09-9120-1-035
0.060 - 0.062 0.109 " 0.530" - - - - - Brass Gold -
09-6010-3-06
09-6010-3-06
09-6010-3-06
0.015 - 0.025 0.140 " 0.693" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
