Non-Insulated
PC Jacks

Filter
09-9230-4-06
09-9230-4-06
09-9230-4-06
0.040 0.185 " 0.340" - Swage Mount 0.147" 1/8 0.076 Brass Electro-Tin Vertical
09-9230-4-063
09-9230-4-063
09-9230-4-063
0.040 0.185 " 0.340" - Swage Mount 0.147" 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9048-1-03
09-9048-1-03
09-9048-1-03
0.040 0.210 " 0.238" - Solder - 1/32 - 5/32 0.104 Brass Gold Vertical
09-9016-3-03
09-9016-3-03
09-9016-3-03
0.025 0.144 " 0.418" Jack/Pin Swage Mount 0.113" 3/32 0.062 Brass Gold Vertical
09-9645-1-035
09-9645-1-035
09-9645-1-035
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Gold Vertical
09-9645-1-04
09-9645-1-04
09-9645-1-04
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Electro-Tin Vertical
09-9646-1-035
09-9646-1-035
09-9646-1-035
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Gold Vertical
09-9646-1-06
09-9646-1-06
09-9646-1-06
0.040 - 0.060 0.255 " 0.290" - Solder - 1/32 - 3/16 0.104 Brass Electro-Tin Vertical
09-9647-1-035
09-9647-1-035
09-9647-1-035
0.032 - 0.046 0.155 " 0.233" - Solder - 1/32 - 5/32 0.104 Brass Gold Vertical
09-9647-1-04
09-9647-1-04
09-9647-1-04
0.032 - 0.046 0.155 " 0.233" - Solder - 1/32 - 5/32 0.104 Brass Electro-Tin Vertical
09-9022-2-035
09-9022-2-035
09-9022-2-035
0.025 0.280 " 0.312" Jack/Jack Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9260-1-088
09-9260-1-088
09-9260-1-088
0.060 - 0.062 0.142 " 0.213" - Press Fit/Solder - 1/16 - 3/32 0.102 Brass Bright Tin-Lead Vertical
09-9725-2-06
09-9725-2-06
09-9725-2-06
0.025 0.141 " 0.294" - Swage Mount 0.094" 1/16 0.058 Brass Electro-Tin Vertical
09-9193-1-03
09-9193-1-03
09-9193-1-03
0.060 - 0.062 0.200 " 0.213" - Press Fit/Solder - 1/16 - 5/32 0.102 Brass Gold Vertical
09-9013-1-063
09-9013-1-063
09-9013-1-063
0.060 - 0.062 0.200 " 0.213" - Solder - 1/32 - 1/8 0.102 Brass Bright Tin-Lead Vertical
09-9193-1-035
09-9193-1-035
09-9193-1-035
0.060 - 0.062 0.200 " 0.213" - Press Fit/Solder - 1/16 - 5/32 0.102 Brass Gold Vertical
09-9193-1-06
09-9193-1-06
09-9193-1-06
0.060 - 0.062 0.200 " 0.213" - Press Fit/Solder - 1/16 - 5/32 0.102 Brass Electro-Tin Vertical
09-9193-1-063
09-9193-1-063
09-9193-1-063
0.060 - 0.062 0.200 " 0.213" - Press Fit/Solder - 1/16 - 5/32 0.102 Brass Bright Tin-Lead Vertical
09-9193-1-088
09-9193-1-088
09-9193-1-088
0.060 - 0.062 0.200 " 0.213" - Press Fit/Solder - 1/16 - 5/32 0.102 Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
