Non-Insulated
PC Jacks

Filter
09-9725-2-088
09-9725-2-088
09-9725-2-088
0.025 0.141 " 0.294" - Swage Mount 0.094" 1/16 0.058 Brass Bright Tin-Lead Vertical
09-9725-2-04
09-9725-2-04
09-9725-2-04
0.025 0.141 " 0.294" - Swage Mount 0.094" 1/16 0.058 Brass Electro-Tin Vertical
09-9725-2-035
09-9725-2-035
09-9725-2-035
0.025 0.141 " 0.294" - Swage Mount 0.094" 1/16 0.058 Brass Gold Vertical
09-9698-1-088
09-9698-1-088
09-9698-1-088
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Bright Tin-Lead Vertical
09-9698-1-063
09-9698-1-063
09-9698-1-063
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Bright Tin-Lead Vertical
09-9698-1-06
09-9698-1-06
09-9698-1-06
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9698-1-035
09-9698-1-035
09-9698-1-035
0.015 - 0.025 0.150 " 0.300" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9695-1-04
09-9695-1-04
09-9695-1-04
0.015 - 0.025 0.145 " 0.261" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9694-1-088
09-9694-1-088
09-9694-1-088
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Phosphor Bronze Bright Tin-Lead Vertical
09-9694-1-04
09-9694-1-04
09-9694-1-04
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Phosphor Bronze Electro-Tin Vertical
09-9694-1-035
09-9694-1-035
09-9694-1-035
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Phosphor Bronze Gold Vertical
09-9694-1-03
09-9694-1-03
09-9694-1-03
0.015 - 0.025 0.146 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.057 Phosphor Bronze Gold Vertical
09-9693-1-088
09-9693-1-088
09-9693-1-088
0.015 - 0.025 0.145 " 0.425" Jack/Pin Press Fit/Solder - 3/32 - 1/4 0.057 Brass Bright Tin-Lead Vertical
09-9693-1-063
09-9693-1-063
09-9693-1-063
0.015 - 0.025 0.145 " 0.425" Jack/Pin Press Fit/Solder - 3/32 - 1/4 0.057 Brass Bright Tin-Lead Vertical
09-9693-1-06
09-9693-1-06
09-9693-1-06
0.015 - 0.025 0.145 " 0.425" Jack/Pin Press Fit/Solder - 3/32 - 1/4 0.057 Brass Electro-Tin Vertical
09-9693-1-03
09-9693-1-03
09-9693-1-03
0.015 - 0.025 0.145 " 0.425" Jack/Pin Press Fit/Solder - 3/32 - 1/4 0.057 Brass Gold Vertical
09-9692-1-088
09-9692-1-088
09-9692-1-088
0.015 - 0.025 0.145 " 0.353" Jack/Pin Press Fit/Solder - 3/32 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9692-1-03
09-9692-1-03
09-9692-1-03
0.015 - 0.025 0.145 " 0.353" Jack/Pin Press Fit/Solder - 3/32 - 1/8 0.057 Brass Gold Vertical
09-9691-1-063
09-9691-1-063
09-9691-1-063
0.015 - 0.025 0.145 " 0.343" Jack/Pin Press Fit/Solder - 3/32 - 3/16 0.057 Brass Bright Tin-Lead Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
