Military
Insulated
Terminals

Filter
1133-03M-0513Z
1133-03M-0513Z
1133-03M-0513Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.086 PTFE Orange M55155/043B03 AA59126/043B03
1125-46M-08810Z
1125-46M-08810Z
1125-46M-08810Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Black M55155/100D02 AA59126/100D02
1125-45M-0510Z
1125-45M-0510Z
1125-45M-0510Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Black M55155/090B02 AA59126/090B02
1169-36M-0510Z
1169-36M-0510Z
1169-36M-0510Z
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Black M55155/090B03 AA59126/090B03
1127-03M-09519Z
1127-03M-09519Z
1127-03M-09519Z
0.593" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE White M55155/199C03 AA59126/199C03
1125-42M-0516Z
1125-42M-0516Z
1125-42M-0516Z
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Blue M55155/106B01 AA59126/106B01
1169-37M-0516Z
1169-37M-0516Z
1169-37M-0516Z
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE Blue M55155/096B04 AA59126/096B04
1125-46M-08811Z
1125-46M-08811Z
1125-46M-08811Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Brown M55155/101D02 AA59126/101D02
1127-03M-09517Z
1127-03M-09517Z
1127-03M-09517Z
0.593" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE Violet M55155/197C03 AA59126/197C03
1133-01M-08817Z
1133-01M-08817Z
1133-01M-08817Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.136 PTFE Violet M55155/047D01 AA59126/047D01
1127-03M-09515Z
1127-03M-09515Z
1127-03M-09515Z
0.593" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE Green M55155/195C03 AA59126/195C03
1127-01M-08811Z
1127-01M-08811Z
1127-01M-08811Z
0.593" - 4-40 Screw - CLEARANCE FOR Screw #4 DIALLYL PHTHALATE Brown M55155/191D01 AA59126/191D01
1110-75M-08813Z
1110-75M-08813Z
1110-75M-08813Z
0.343" Pin/Pin Press Fit 1/16 0.086 PTFE Orange M55155/033D05 AA59126/033D05
1127-02M-08818Z
1127-02M-08818Z
1127-02M-08818Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Gray M55155/198D02 AA59126/198D02
1127-03M-09514Z
1127-03M-09514Z
1127-03M-09514Z
0.593" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE Yellow M55155/194C03 AA59126/194C03
1125-42M-09512Z
1125-42M-09512Z
1125-42M-09512Z
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Red M55155/102C01 AA59126/102C01
1110-75M-08816Z
1110-75M-08816Z
1110-75M-08816Z
0.343" Pin/Pin Press Fit 1/16 0.086 PTFE Blue M55155/036D05 AA59126/036D05
1133-03M-09517Z
1133-03M-09517Z
1133-03M-09517Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.086 PTFE Violet M55155/047C03 AA59126/047C03
1125-46M-0512Z
1125-46M-0512Z
1125-46M-0512Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Red M55155/102B02 AA59126/102B02
1100-07M-08817Z
1100-07M-08817Z
1100-07M-08817Z
0.350" - Press Fit 1/16 0.086 PTFE Violet M55155/087D02 AA59126/087D02

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
