Military
Insulated
Terminals

Filter
1127-01M-08815Z
1127-01M-08815Z
1127-01M-08815Z
0.593" - 4-40 Screw - CLEARANCE FOR Screw #4 DIALLYL PHTHALATE Green M55155/195D01 AA59126/195D01
1125-46M-0511Z
1125-46M-0511Z
1125-46M-0511Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Brown M55155/101B02 AA59126/101B02
1125-42M-0514Z
1125-42M-0514Z
1125-42M-0514Z
0.546" - 4-40 Screw - CLEARANCE FOR Screw #4 PTFE Yellow M55155/104B01 AA59126/104B01
1127-01M-0512Z
1127-01M-0512Z
1127-01M-0512Z
0.593" - 4-40 Screw - CLEARANCE FOR Screw #4 DIALLYL PHTHALATE Red M55155/192B01 AA59126/192B01
1127-02M-09516Z
1127-02M-09516Z
1127-02M-09516Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Blue M55155/196C02 AA59126/196C02
1127-02M-09515Z
1127-02M-09515Z
1127-02M-09515Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Green M55155/195C02 AA59126/195C02
1127-03M-0510Z
1127-03M-0510Z
1127-03M-0510Z
0.593" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE Black M55155/190B03 AA59126/190B03
1127-01M-0510Z
1127-01M-0510Z
1127-01M-0510Z
0.593" - 4-40 Screw - CLEARANCE FOR Screw #4 DIALLYL PHTHALATE Black M55155/190B01 AA59126/190B01
1127-02M-09513Z
1127-02M-09513Z
1127-02M-09513Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Orange M55155/193C02 AA59126/193C02
1127-02M-09511Z
1127-02M-09511Z
1127-02M-09511Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Brown M55155/191C02 AA59126/191C02
1127-02M-09510Z
1127-02M-09510Z
1127-02M-09510Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Black M55155/190C02 AA59126/190C02
1125-43M-08814Z
1125-43M-08814Z
1125-43M-08814Z
0.750" - 4-40 Nut 1/8 0.120 PTFE Yellow M55155/094D01 AA59126/094D01
1125-46M-09518Z
1125-46M-09518Z
1125-46M-09518Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Gray M55155/108C02 AA59126/108C02
1127-03M-08811Z
1127-03M-08811Z
1127-03M-08811Z
0.593" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE Brown M55155/191D03 AA59126/191D03
1125-43M-08819Z
1125-43M-08819Z
1125-43M-08819Z
0.750" - 4-40 Nut 1/8 0.120 PTFE White M55155/099D01 AA59126/099D01
1127-01M-09510Z
1127-01M-09510Z
1127-01M-09510Z
0.593" - 4-40 Screw - CLEARANCE FOR Screw #4 DIALLYL PHTHALATE Black M55155/190C01 AA59126/190C01
1125-46M-08816Z
1125-46M-08816Z
1125-46M-08816Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Blue M55155/106D02 AA59126/106D02
1125-45M-0518Z
1125-45M-0518Z
1125-45M-0518Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Gray M55155/098B02 AA59126/098B02
1127-02M-0516Z
1127-02M-0516Z
1127-02M-0516Z
0.423" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Blue M55155/196B02 AA59126/196B02
1100-07M-08817Z
1100-07M-08817Z
1100-07M-08817Z
0.350" - Press Fit 1/16 0.086 PTFE Violet M55155/087D02 AA59126/087D02

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
