Commercial
Non-Insulated
Terminals

Filter
10-525-1-088
10-525-1-088
10-525-1-088
0.489" - Double Turret/Double Turret Swage Mount 0.053" 1/32 0.094 Brass Bright Tin-Lead NO
10-8025-1-088
10-8025-1-088
10-8025-1-088
0.348" 0.040 TURRET/PIN Swage Mount 0.051" 1/32 0.076 Brass Bright Tin-Lead NO
10-306-1-088
10-306-1-088
10-306-1-088
0.263" - - Swage Mount 0.075" 1/32 0.113 Brass Bright Tin-Lead NO
10-801-6-088
10-801-6-088
10-801-6-088
0.535" 0.040 TURRET/PIN Swage Mount 0.207" 3/16 0.076 Brass Bright Tin-Lead NO
10-8015-6-088
10-8015-6-088
10-8015-6-088
0.582" 0.040 TURRET/PIN Swage Mount 0.207" 3/16 0.076 Brass Bright Tin-Lead NO
10-8024-1-088
10-8024-1-088
10-8024-1-088
0.448" 0.080 - Swage Mount 0.051" 1/32 0.094 Brass Bright Tin-Lead NO
10-8016-3-088
10-8016-3-088
10-8016-3-088
0.643" 0.080 - Swage Mount 0.113" 3/32 0.094 Brass Bright Tin-Lead NO
10-8016-2-088
10-8016-2-088
10-8016-2-088
0.612" 0.080 - Swage Mount 0.082" 1/16 0.094 Brass Bright Tin-Lead NO
10-408-2-088
10-408-2-088
10-408-2-088
0.417" - - Swage Mount 0.105" 1/16 0.116 Brass Bright Tin-Lead NO
10-8008-3-088
10-8008-3-088
10-8008-3-088
0.525" 0.080 - Swage Mount 0.125" 3/32 0.094 Brass Bright Tin-Lead NO
10-541-4-088
10-541-4-088
10-541-4-088
0.634" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.116 Brass Bright Tin-Lead NO
10-541-3-088
10-541-3-088
10-541-3-088
0.604" - TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.116 Brass Bright Tin-Lead NO
10-8008-2-088
10-8008-2-088
10-8008-2-088
0.494" 0.080 - Swage Mount 0.094" 1/16 0.094 Brass Bright Tin-Lead NO
10-805-4-088
10-805-4-088
10-805-4-088
0.462" - - Swage Mount 0.172" 1/8 0.094 Brass Bright Tin-Lead NO
10-808-3-088
10-808-3-088
10-808-3-088
0.612" - - Swage Mount 0.141" 3/32 0.094 Brass Bright Tin-Lead NO
09-8344-2-088
09-8344-2-088
09-8344-2-088
0.349" 0.080 PIN/TURRET Swage Mount 0.082" 1/16 0.1285 Brass Bright Tin-Lead NO
10-217-2-088
10-217-2-088
10-217-2-088
0.449" - - Swage Mount 0.105" 1/16 0.116 Brass Bright Tin-Lead NO
10-963-2-088
10-963-2-088
10-963-2-088
0.344" 0.020 (+0.000/-0.005) - Swage Mount 0.094" 1/16 0.036 Brass Bright Tin-Lead NO
10-543-3-088
10-543-3-088
10-543-3-088
0.570" - Double Turret/Double Turret Swage Mount 0.125" 3/32 0.094 Brass Bright Tin-Lead NO
09-8138-1-088
09-8138-1-088
09-8138-1-088
0.093" 0.020 - Swage Mount 0.053" 1/32 0.037 Brass Bright Tin-Lead NO
