Commercial
Non-Insulated
Terminals

Filter
10-466-2-04
10-466-2-04
10-466-2-04
0.340" - TURRET/THREAD Swage Mount 0.082" 1/16 0.076 Brass Electro-Tin YES
10-449-11-088
10-449-11-088
10-449-11-088
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Bright Tin-Lead NO
10-329-5-088
10-329-5-088
10-329-5-088
0.531" - - Swage Mount 0.203" 5/32 0.125 Brass Bright Tin-Lead NO
10-882-4-088
10-882-4-088
10-882-4-088
0.625" - Turret/Turret Swage Mount 0.165" 1/8 0.147 Brass Bright Tin-Lead NO
10-803-8-088
10-803-8-088
10-803-8-088
0.645" 0.040 TURRET/PIN Swage Mount 0.270" 1/4 0.076 Brass Bright Tin-Lead NO
09-8178-2-05
09-8178-2-05
09-8178-2-05
0.531" 0.025 - Swage Mount 0.094" 1/16 0.052 Brass Electro Solder NO
09-8301-2-044
09-8301-2-044
09-8301-2-044
0.248" 0.017 - Solder 0.075" 1/64 TO 3/64 0.0225 Brass Bright Tin YES
10-458-2-01
10-458-2-01
10-458-2-01
0.282" - - Swage Mount 0.094" 1/16 0.076 Brass Silver YES
10-227-1-03
10-227-1-03
10-227-1-03
0.209" - - Swage Mount 0.053" 1/32 0.043 Brass Gold YES
10-817-2-03
10-817-2-03
10-817-2-03
0.629" - - Swage Mount 0.109" 1/16 0.1495 Brass Gold YES
10-448-2-03
10-448-2-03
10-448-2-03
0.396" - - Swage Mount 0.084" 1/16 0.063 Brass Gold YES
09-0303-3-05
09-0303-3-05
09-0303-3-05
0.271" - - Swage Mount 0.115" 3/32 0.063 Brass Electro Solder NO
10-809-8-05
10-809-8-05
10-809-8-05
0.383" - - Swage Mount 0.297" 1/4 0.116 Brass Electro Solder NO
10-812-4-05
10-812-4-05
10-812-4-05
0.656" - Turret/Turret Swage Mount 0.156" 1/8 0.147 Brass Electro Solder NO
10-203-2-05
10-203-2-05
10-203-2-05
0.390" - - Swage Mount 0.109" 1/16 0.094 Brass Electro Solder NO
10-330-2A-044
10-330-2A-044
10-330-2A-044
0.312" - - Swage Mount 0.094" 1/16 0.086 Brass Bright Tin YES
10-414-1-044
10-414-1-044
10-414-1-044
0.207" - - Swage Mount 0.051" 1/32 0.052 Brass Bright Tin YES
10-919-2-044
10-919-2-044
10-919-2-044
0.252" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Bright Tin YES
10-439-2-044
10-439-2-044
10-439-2-044
0.586" - - Swage Mount 0.105" 1/16 0.1875 Brass Bright Tin YES
09-8349-2-044
09-8349-2-044
09-8349-2-044
0.270" 0.018 - Solder 0.100" 1/64 TO 1/16 0.020 Brass Bright Tin YES
