Commercial
Insulated
Pin Terminals

Filter
09-2034-1-04411
09-2034-1-04411
09-2034-1-04411
1.200" 0.056 Pin/Pin Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Brown NO
09-2104-1-0415
09-2104-1-0415
09-2104-1-0415
0.460" 0.036 Pin/Pin Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Green YES
1169-37-08814
1169-37-08814
1169-37-08814
0.750" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Bright Tin-Lead Brass DIALLYL PHTHALATE Yellow NO
09-2117-1-08812
09-2117-1-08812
09-2117-1-08812
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Red NO
09-2117-1-08817
09-2117-1-08817
09-2117-1-08817
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Violet NO
09-2117-1-08814
09-2117-1-08814
09-2117-1-08814
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Yellow NO
09-2117-1-08818
09-2117-1-08818
09-2117-1-08818
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Gray NO
09-2117-1-08810
09-2117-1-08810
09-2117-1-08810
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Black NO
09-2117-1-08819
09-2117-1-08819
09-2117-1-08819
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE White NO
09-2117-1-08811
09-2117-1-08811
09-2117-1-08811
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Brown NO
09-2094-1-08818
09-2094-1-08818
09-2094-1-08818
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Bright Tin-Lead - - PTFE Gray NO
1124-10-04410
1124-10-04410
1124-10-04410
0.899" 0.050 THREAD/TIP Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Black YES
1115-10-0113
1115-10-0113
1115-10-0113
0.375" 0.040 - Press Fit 3/32 0.077 Brass Silver - - PTFE Orange NO
1127-10-0414
1127-10-0414
1127-10-0414
0.759" 0.070 - Swage Mount 1/16 0.104 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Yellow YES
1115-10-0310
1115-10-0310
1115-10-0310
0.375" 0.040 - Press Fit 3/32 0.077 Brass Gold - - PTFE Black YES
1107-10-0317
1107-10-0317
1107-10-0317
0.515" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Gold - - PTFE Violet YES
1107-10-0313
1107-10-0313
1107-10-0313
0.515" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Gold - - PTFE Orange NO
1112-10-0416
1112-10-0416
1112-10-0416
0.303" - - Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Blue YES
1124-10-0110
1124-10-0110
1124-10-0110
0.899" 0.050 THREAD/TIP Press Fit Up to 3/16 0.158 Brass Silver - - PTFE Black YES
1132-10-0414
1132-10-0414
1132-10-0414
0.855" 0.080 - Solder 11/32 0.086 Brass Electro-Tin - - PTFE Yellow NO
