Commercial
Insulated
Pin Terminals

Filter
1124-11-04412
1124-11-04412
1124-11-04412
1.024" 0.050 THREAD/TIP Press Fit Up to 1/4 0.158 Brass Bright Tin - - PTFE Red NO
1112-11-0519
1112-11-0519
1112-11-0519
0.238" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE White NO
1112-11-0517
1112-11-0517
1112-11-0517
0.238" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Violet NO
1112-11-0516
1112-11-0516
1112-11-0516
0.238" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Blue NO
1112-11-0513
1112-11-0513
1112-11-0513
0.238" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Orange NO
1102R-11-04414
1102R-11-04414
1102R-11-04414
0.296" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Yellow NO
1110-11-08812
1110-11-08812
1110-11-08812
0.515" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin-Lead - - PTFE Red NO
1102R-11-04418
1102R-11-04418
1102R-11-04418
0.296" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Gray NO
1125-11-0410
1125-11-0410
1125-11-0410
0.454" - - Swage Mount 1/16 0.116 ±0.002 Brass Electro-Tin Electro-Tin Brass PTFE Black YES
1111-11-08810
1111-11-08810
1111-11-08810
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Black NO
1111-11-08812
1111-11-08812
1111-11-08812
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1125-11-0413
1125-11-0413
1125-11-0413
0.454" - - Swage Mount 1/16 0.116 ±0.002 Brass Electro-Tin Electro-Tin Brass PTFE Orange NO
1125-11-0417
1125-11-0417
1125-11-0417
0.454" - - Swage Mount 1/16 0.116 ±0.002 Brass Electro-Tin Electro-Tin Brass PTFE Violet YES
1133-11-0415
1133-11-0415
1133-11-0415
1.052" 0.040 DOUBLE TURRET/PIN Press Fit Up to 1/4 0.172 Brass Electro-Tin - - PTFE Green YES
1111-11-08816
1111-11-08816
1111-11-08816
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1114R-11-08817
1114R-11-08817
1114R-11-08817
0.225" 0.045 (+0.000/-0.005) - Press Fit 1/32 0.113 Brass Bright Tin-Lead - - PTFE Violet NO
1111-11-08818
1111-11-08818
1111-11-08818
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
1102-11-0119
1102-11-0119
1102-11-0119
0.296" - - Press Fit 1/16 0.136 Brass Silver - - PTFE White YES
1102-11-0114
1102-11-0114
1102-11-0114
0.296" - - Press Fit 1/16 0.136 Brass Silver - - PTFE Yellow NO
1133-11-0416
1133-11-0416
1133-11-0416
1.052" 0.040 DOUBLE TURRET/PIN Press Fit Up to 1/4 0.172 Brass Electro-Tin - - PTFE Blue YES
