Commercial
Insulated
Pin Terminals

Filter
09-2117-1-0510
09-2117-1-0510
09-2117-1-0510
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Electro Solder Nickel Brass PTFE Black NO
09-2117-1-0517
09-2117-1-0517
09-2117-1-0517
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Electro Solder Nickel Brass PTFE Violet NO
09-2117-1-0519
09-2117-1-0519
09-2117-1-0519
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Electro Solder Nickel Brass PTFE White NO
09-2010-1-0416
09-2010-1-0416
09-2010-1-0416
0.436" 0.040 Pin/Tip Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Blue YES
09-2128-1-08810
09-2128-1-08810
09-2128-1-08810
0.443" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Black NO
09-2090-1-08815
09-2090-1-08815
09-2090-1-08815
1.260" 0.040 (+0.001/-0.005) Pin/Pin Press Fit 1/32 0.076 Brass Bright Tin-Lead - - PTFE Green NO
09-2090-1-08818
09-2090-1-08818
09-2090-1-08818
1.260" 0.040 (+0.001/-0.005) Pin/Pin Press Fit 1/32 0.076 Brass Bright Tin-Lead - - PTFE Gray NO
09-2104-1-0411
09-2104-1-0411
09-2104-1-0411
0.460" 0.036 Pin/Pin Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Brown NO
09-2090-1-08819
09-2090-1-08819
09-2090-1-08819
1.260" 0.040 (+0.001/-0.005) Pin/Pin Press Fit 1/32 0.076 Brass Bright Tin-Lead - - PTFE White NO
09-2034-1-04411
09-2034-1-04411
09-2034-1-04411
1.200" 0.056 Pin/Pin Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Brown NO
09-2104-1-0415
09-2104-1-0415
09-2104-1-0415
0.460" 0.036 Pin/Pin Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Green YES
1169-37-08814
1169-37-08814
1169-37-08814
0.750" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Bright Tin-Lead Brass DIALLYL PHTHALATE Yellow NO
09-2117-1-08812
09-2117-1-08812
09-2117-1-08812
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Red NO
09-2117-1-08817
09-2117-1-08817
09-2117-1-08817
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Violet NO
09-2117-1-08814
09-2117-1-08814
09-2117-1-08814
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Yellow NO
09-2117-1-08818
09-2117-1-08818
09-2117-1-08818
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Gray NO
09-2117-1-08810
09-2117-1-08810
09-2117-1-08810
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Black NO
09-2117-1-08819
09-2117-1-08819
09-2117-1-08819
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE White NO
09-2117-1-08811
09-2117-1-08811
09-2117-1-08811
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Nickel Brass PTFE Brown NO
09-2094-1-08818
09-2094-1-08818
09-2094-1-08818
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Bright Tin-Lead - - PTFE Gray NO
