Commercial
Insulated
Pin Terminals

Filter
1106-02-0515
1106-02-0515
1106-02-0515
0.478" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Green NO
1125-97-08818
1125-97-08818
1125-97-08818
0.672" - - 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead ZINC Brass PTFE Gray NO
1106-02-0518
1106-02-0518
1106-02-0518
0.478" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Gray NO
1105-02-0415
1105-02-0415
1105-02-0415
1.687" - Double Turret/Double Turret Press Fit 9/16 0.205 Brass Electro-Tin - - PTFE Green YES
1125-17-0314
1125-17-0314
1125-17-0314
0.698" - - 6-32 Nut 1/16 0.144 Brass Gold Electro-Tin Brass PTFE Yellow NO
1104-53-0110
1104-53-0110
1104-53-0110
0.555" - - Press Fit 1/8 0.158 Brass Silver - - PTFE Black YES
1127-32-0112
1127-32-0112
1127-32-0112
0.844" - - 6-32 Nut 1/8 0.144 Brass Silver ZINC Brass DIALLYL PHTHALATE Red YES
1125-50-0312
1125-50-0312
1125-50-0312
0.788" - - 6-32 Nut 1/16 0.144 Brass Gold Electro-Tin Brass PTFE Red NO
1103R-09-0510
1103R-09-0510
1103R-09-0510
0.320" - - Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Black NO
1102R-77-0111
1102R-77-0111
1102R-77-0111
0.583" - - Press Fit Up to 1/4 0.172 Brass Silver - - PTFE Brown NO
1127-32-0311
1127-32-0311
1127-32-0311
0.844" - - 6-32 Nut 1/8 0.144 Brass Gold ZINC Brass DIALLYL PHTHALATE Brown YES
1125-37-0418
1125-37-0418
1125-37-0418
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Electro-Tin Electro-Tin Brass PTFE Gray NO
1102R-28-0518
1102R-28-0518
1102R-28-0518
0.361" - - Press Fit 1/8 0.140 Brass Electro Solder - - PTFE Gray NO
1102-99-0511
1102-99-0511
1102-99-0511
0.269" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Brown NO
1125-85-0415
1125-85-0415
1125-85-0415
0.698" - - 6-32 Nut 1/16 0.144 Brass Electro-Tin Electro-Tin Brass PTFE Green YES
1102-94-08810
1102-94-08810
1102-94-08810
0.649" - - Press Fit Up to 3/16 0.191 Brass Bright Tin-Lead - - PTFE Black NO
1125-37-0417
1125-37-0417
1125-37-0417
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Electro-Tin Electro-Tin Brass PTFE Violet YES
1156-07-0313
1156-07-0313
1156-07-0313
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 3/32 0.136 Brass Gold - - PTFE Orange NO
1125-74-0319
1125-74-0319
1125-74-0319
0.947" - - 6-32 Nut Up to 1/4 0.144 Brass Gold ZINC Brass PTFE White YES
1125-37-0317
1125-37-0317
1125-37-0317
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Gold Electro-Tin Brass PTFE Violet YES
