Commercial
Insulated
Pin Terminals

1178R-09-0313
1178R-09-0313
1178R-09-0313
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Gold - - PTFE Orange NO
1178R-09-0316
1178R-09-0316
1178R-09-0316
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Gold - - PTFE Blue YES
1131-09-0311
1131-09-0311
1131-09-0311
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Brown NO
1100-09-0314
1100-09-0314
1100-09-0314
0.350" 0.040 - Press Fit 3/32 0.098 Brass Gold - - PTFE Yellow NO
1100-09-0317
1100-09-0317
1100-09-0317
0.350" 0.040 - Press Fit 3/32 0.098 Brass Gold - - PTFE Violet YES
1103R-09-0319
1103R-09-0319
1103R-09-0319
0.320" - - Press Fit 1/8 0.136 Brass Gold - - PTFE White YES
1103R-09-0312
1103R-09-0312
1103R-09-0312
0.320" - - Press Fit 1/8 0.136 Brass Gold - - PTFE Red NO
1111-09-0316
1111-09-0316
1111-09-0316
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
1178R-09-0112
1178R-09-0112
1178R-09-0112
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Silver - - PTFE Red NO
1114R-09-0110
1114R-09-0110
1114R-09-0110
0.193" 0.050 - Press Fit 1/32 0.113 Brass Silver - - PTFE Black YES
1112-09-0116
1112-09-0116
1112-09-0116
0.293" - - Press Fit 1/64 0.113 Brass Silver - - PTFE Blue YES
1100R-09-0314
1100R-09-0314
1100R-09-0314
0.350" 0.040 - Press Fit 3/32 0.098 Brass Gold - - PTFE Yellow NO
1100R-09-0313
1100R-09-0313
1100R-09-0313
0.350" 0.040 - Press Fit 3/32 0.098 Brass Gold - - PTFE Orange NO
1178R-09-08818
1178R-09-08818
1178R-09-08818
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Bright Tin-Lead - - PTFE Gray NO
1178R-09-08814
1178R-09-08814
1178R-09-08814
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Bright Tin-Lead - - PTFE Yellow NO
1178R-09-08813
1178R-09-08813
1178R-09-08813
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Bright Tin-Lead - - PTFE Orange NO
1178R-09-08815
1178R-09-08815
1178R-09-08815
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Bright Tin-Lead - - PTFE Green NO
1178R-09-08810
1178R-09-08810
1178R-09-08810
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Bright Tin-Lead - - PTFE Black NO
1151-09-0316
1151-09-0316
1151-09-0316
0.390" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
1106-09-0317
1106-09-0317
1106-09-0317
0.603" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Violet YES
