Commercial
Insulated
Pin Terminals

Filter
1127-60-04419
1127-60-04419
1127-60-04419
0.642" - - 2-56 Nut 1/16 0.094 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE White YES
1167-60-08818
1167-60-08818
1167-60-08818
1.062" - - 6-32 Nut 3/32 0.144 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Gray NO
1167-60-08819
1167-60-08819
1167-60-08819
1.062" - - 6-32 Nut 3/32 0.144 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE White NO
1123R-60-04417
1123R-60-04417
1123R-60-04417
0.477" 0.050 Pin/Slotted Press Fit 5/32 0.136 Brass Bright Tin - - PTFE Violet YES
1123R-60-04415
1123R-60-04415
1123R-60-04415
0.477" 0.050 Pin/Slotted Press Fit 5/32 0.136 Brass Bright Tin - - PTFE Green YES
1125-60-0419
1125-60-0419
1125-60-0419
1.297" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro-Tin ZINC Brass PTFE White YES
1102-60-0317
1102-60-0317
1102-60-0317
0.485" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Violet YES
1110-60-0115
1110-60-0115
1110-60-0115
0.443" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Silver - - PTFE Green YES
1125-60-0410
1125-60-0410
1125-60-0410
1.297" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro-Tin ZINC Brass PTFE Black YES
1111-60-0113
1111-60-0113
1111-60-0113
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Silver - - PTFE Orange NO
1123R-60-0413
1123R-60-0413
1123R-60-0413
0.477" 0.050 Pin/Slotted Press Fit 5/32 0.136 Brass Electro-Tin - - PTFE Orange NO
1127-60-08818
1127-60-08818
1127-60-08818
0.642" - - 2-56 Nut 1/16 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Gray NO
1102-60-04418
1102-60-04418
1102-60-04418
0.485" - - Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Gray NO
1111-60-04413
1111-60-04413
1111-60-04413
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Orange NO
1177-60-0419
1177-60-0419
1177-60-0419
0.887" 0.050 Pin/Pin PRESS LOCK 1/32 - 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1127-60-0411
1127-60-0411
1127-60-0411
0.642" - - 2-56 Nut 1/16 0.094 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Brown YES
1127-60-0415
1127-60-0415
1127-60-0415
0.642" - - 2-56 Nut 1/16 0.094 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Green YES
1127-60-0511
1127-60-0511
1127-60-0511
0.642" - - 2-56 Nut 1/16 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Brown NO
1111-60-08812
1111-60-08812
1111-60-08812
0.550" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1167-60-0310
1167-60-0310
1167-60-0310
1.062" - - 6-32 Nut 3/32 0.144 Brass Gold ZINC Brass DIALLYL PHTHALATE Black YES

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
