Commercial
Insulated
Pin Terminals

Filter
1175-372-0317
1175-372-0317
1175-372-0317
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Gold - - PTFE Violet YES
1175-372-0315
1175-372-0315
1175-372-0315
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Gold - - PTFE Green YES
1175-372-0516
1175-372-0516
1175-372-0516
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Blue NO
1175-372-0514
1175-372-0514
1175-372-0514
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Yellow NO
1175-372-0513
1175-372-0513
1175-372-0513
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Orange NO
1175-372-08810
1175-372-08810
1175-372-08810
0.736" 0.040 DOUBLE TURRET/PIN PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Black NO
1102-93-08812
1102-93-08812
1102-93-08812
0.415" - - Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1102-93-0116
1102-93-0116
1102-93-0116
0.415" - - Press Fit 1/8 0.136 Brass Silver - - PTFE Blue YES
1102R-93-0519
1102R-93-0519
1102R-93-0519
0.415" - - Press Fit 1/8 0.136 Brass Electro Solder - - PTFE White NO
1127-92-08810
1127-92-08810
1127-92-08810
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Black NO
1127-92-0519
1127-92-0519
1127-92-0519
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE White NO
1102R-92-0316
1102R-92-0316
1102R-92-0316
0.460" - - Press Fit 3/32 0.172 Brass Gold - - PTFE Blue YES
1127-92-08815
1127-92-08815
1127-92-08815
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Green NO
1127-92-04411
1127-92-04411
1127-92-04411
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Brown YES
1127-92-04415
1127-92-04415
1127-92-04415
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Green YES
1127-92-04416
1127-92-04416
1127-92-04416
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1127-92-0318
1127-92-0318
1127-92-0318
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE Gray YES
1127-92-0319
1127-92-0319
1127-92-0319
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE White YES
1127-92-0513
1127-92-0513
1127-92-0513
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Orange NO
1127-92-0515
1127-92-0515
1127-92-0515
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Green NO
