Commercial
Insulated
Pin Terminals

Filter
1125-76-0113
1125-76-0113
1125-76-0113
0.666" - - Swage Mount 1/16 0.194 Brass Silver ZINC Brass PTFE Orange NO
1125-76-0112
1125-76-0112
1125-76-0112
0.666" - - Swage Mount 1/16 0.194 Brass Silver ZINC Brass PTFE Red NO
1125-76-0111
1125-76-0111
1125-76-0111
0.666" - - Swage Mount 1/16 0.194 Brass Silver ZINC Brass PTFE Brown NO
1125-76-0110
1125-76-0110
1125-76-0110
0.666" - - Swage Mount 1/16 0.194 Brass Silver ZINC Brass PTFE Black YES
1125-76-0118
1125-76-0118
1125-76-0118
0.666" - - Swage Mount 1/16 0.194 Brass Silver ZINC Brass PTFE Gray NO
1127-76-0114
1127-76-0114
1127-76-0114
0.750" - - Swage Mount 3/32 0.104 Brass Silver ZINC Brass DIALLYL PHTHALATE Yellow YES
1127-76-0511
1127-76-0511
1127-76-0511
0.750" - - Swage Mount 3/32 0.104 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Brown NO
1110-76-08816
1110-76-08816
1110-76-08816
0.450" 0.018 Pin/Pin Press Fit 1/32 0.054 Brass Bright Tin-Lead - - PTFE Blue NO
1127-76-08816
1127-76-08816
1127-76-08816
0.750" - - Swage Mount 3/32 0.104 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Blue NO
1127-76-0410
1127-76-0410
1127-76-0410
0.750" - - Swage Mount 3/32 0.104 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Black YES
1127-20-08810
1127-20-08810
1127-20-08810
0.907" - - Swage Mount 1/16 0.104 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Black NO
1167-20-0412
1167-20-0412
1167-20-0412
0.843" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Red YES
1111-20-0516
1111-20-0516
1111-20-0516
0.836" 0.050 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Blue NO
1125-20-08814
1125-20-08814
1125-20-08814
0.885" - - 6-32 Nut 7/32 0.144 Brass Bright Tin-Lead Electro-Tin Brass PTFE Yellow NO
1125-20-08817
1125-20-08817
1125-20-08817
0.885" - - 6-32 Nut 7/32 0.144 Brass Bright Tin-Lead Electro-Tin Brass PTFE Violet NO
1125-20-08818
1125-20-08818
1125-20-08818
0.885" - - 6-32 Nut 7/32 0.144 Brass Bright Tin-Lead Electro-Tin Brass PTFE Gray NO
1100-20-08814
1100-20-08814
1100-20-08814
0.365" 0.040 - Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1100-20-08813
1100-20-08813
1100-20-08813
0.365" 0.040 - Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1114R-20-0119
1114R-20-0119
1114R-20-0119
0.310" 0.040 - Press Fit 1/64 0.136 Brass Silver - - PTFE White YES
1114R-20-0117
1114R-20-0117
1114R-20-0117
0.310" 0.040 - Press Fit 1/64 0.136 Brass Silver - - PTFE Violet YES
