Non-Insulated
PC Jacks

Filter
09-9019-4-088
09-9019-4-088
09-9019-4-088
(0.025 & 0.040) 0.163 " 0.389" Jack/Jack Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9282-1-063
09-9282-1-063
09-9282-1-063
0.040 0.210 " 0.740" Jack/Threaded 4-40 Nut 0.450" 13/64 - 1/4 0.120 Brass Bright Tin-Lead Vertical
09-9282-1-04
09-9282-1-04
09-9282-1-04
0.040 0.210 " 0.740" Jack/Threaded 4-40 Nut 0.450" 13/64 - 1/4 0.120 Brass Electro-Tin Vertical
09-9281-1-088
09-9281-1-088
09-9281-1-088
0.030 - 0.032 0.190 " 0.388" Jack/Turret Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9281-1-06
09-9281-1-06
09-9281-1-06
0.030 - 0.032 0.190 " 0.388" Jack/Turret Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9624-1-063
09-9624-1-063
09-9624-1-063
0.015 - 0.025 0.142 " 0.161" - Solder - 1/32 - 3/32 0.059 Brass Bright Tin-Lead Vertical
09-9611-1-04
09-9611-1-04
09-9611-1-04
0.015 - 0.025 0.150 " 0.474" Jack/Pin Press Fit/Solder - 1/16 - 1/4 0.059 Brass Electro-Tin Vertical
09-9611-1-06
09-9611-1-06
09-9611-1-06
0.015 - 0.025 0.150 " 0.474" Jack/Pin Press Fit/Solder - 1/16 - 1/4 0.059 Brass Electro-Tin Vertical
09-9611-1-088
09-9611-1-088
09-9611-1-088
0.015 - 0.025 0.150 " 0.474" Jack/Pin Press Fit/Solder - 1/16 - 1/4 0.059 Brass Bright Tin-Lead Vertical
09-9273-1-0355
09-9273-1-0355
09-9273-1-0355
0.030 0.165 " 0.250" - Solder - 1/32 - 1/8 0.076 Brass Gold Vertical
09-9660-1-03
09-9660-1-03
09-9660-1-03
0.015 - 0.025 0.147 " 0.296" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.059 Brass Gold Vertical
09-9660-1-04
09-9660-1-04
09-9660-1-04
0.015 - 0.025 0.147 " 0.296" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.059 Brass Electro-Tin Vertical
09-9270-1-063
09-9270-1-063
09-9270-1-063
0.040 0.350 " 0.374" - Solder - 1/32 - 5/16 0.076 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9697-1-088
09-9697-1-088
09-9697-1-088
0.015 - 0.025 0.150 " 0.356" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.059 Brass Bright Tin-Lead Vertical
09-9729-1-035
09-9729-1-035
09-9729-1-035
0.032 - 0.046 0.220 " 0.253" - Solder - 1/32 - 3/16 0.0935 Brass Gold Vertical
09-9734-1-035
09-9734-1-035
09-9734-1-035
0.032 - 0.046 0.250 " 0.288" - Solder - 1/32 - 3/32 0.125 Brass Gold Vertical
09-9734-1-04
09-9734-1-04
09-9734-1-04
0.032 - 0.046 0.250 " 0.288" - Solder - 1/32 - 3/32 0.125 Brass Electro-Tin Vertical
09-9728-1-088
09-9728-1-088
09-9728-1-088
0.032 - 0.046 0.137 " 0.206" - Solder - 1/32 - 5/32 0.076 Brass Bright Tin-Lead Vertical
09-9660-1-06
09-9660-1-06
09-9660-1-06
0.015 - 0.025 0.147 " 0.296" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.059 Brass Electro-Tin Vertical
09-9727-1-088
09-9727-1-088
09-9727-1-088
0.032 - 0.046 0.241 " 0.270" - Solder - 1/32 - 3/16 0.075 Brass Bright Tin-Lead Vertical
