Non-Insulated
PC Jacks

Filter
09-9005-4-063
09-9005-4-063
09-9005-4-063
0.040 0.190 " 0.543" Jack/Pin Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9626-2-035
09-9626-2-035
09-9626-2-035
0.025 - 0.037 0.180 " 0.397" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Gold Vertical
09-9607-1-03
09-9607-1-03
09-9607-1-03
0.015 - 0.025 0.150 " 0.446" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Gold Vertical
09-9607-1-06
09-9607-1-06
09-9607-1-06
0.015 - 0.025 0.150 " 0.446" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Electro-Tin Vertical
09-9607-1-088
09-9607-1-088
09-9607-1-088
0.015 - 0.025 0.150 " 0.446" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Bright Tin-Lead Vertical
09-9609-1-03
09-9609-1-03
09-9609-1-03
0.015 - 0.025 0.150 " 0.343" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Gold Vertical
09-9609-1-06
09-9609-1-06
09-9609-1-06
0.015 - 0.025 0.150 " 0.343" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Electro-Tin Vertical
09-9022-3-035
09-9022-3-035
09-9022-3-035
0.025 0.308 " 0.343" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9022-3-04
09-9022-3-04
09-9022-3-04
0.025 0.308 " 0.343" Jack/Jack Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9051-2-088
09-9051-2-088
09-9051-2-088
0.016 - 0.020 0.210 " 0.287" Jack/Turret Swage Mount 0.072" 1/16 0.076 Brass Bright Tin-Lead Vertical
09-9051-4-03
09-9051-4-03
09-9051-4-03
0.016 - 0.020 0.210 " 0.287" Jack/Turret Swage Mount 0.135" 1/8 0.076 Brass Gold Vertical
09-9042-4-04
09-9042-4-04
09-9042-4-04
0.080 0.375 " 0.699" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-3-06
09-9042-3-06
09-9042-3-06
0.080 0.375 " 0.668" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9042-2-04
09-9042-2-04
09-9042-2-04
0.080 0.375 " 0.637" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9610-1-03
09-9610-1-03
09-9610-1-03
0.015 - 0.025 0.150 " 0.356" Jack/Pin Press Fit/Solder - 1/16 - 1/8 0.057 Brass Gold Vertical
09-9042-2-035
09-9042-2-035
09-9042-2-035
0.080 0.375 " 0.637" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9042-1-088
09-9042-1-088
09-9042-1-088
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9613-1-04
09-9613-1-04
09-9613-1-04
0.015 - 0.025 0.148 " 0.173" - Press Fit/Solder - 1/16 - 1/8 0.057 Brass Electro-Tin Vertical
09-9042-1-035
09-9042-1-035
09-9042-1-035
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9613-1-06
09-9613-1-06
09-9613-1-06
0.015 - 0.025 0.148 " 0.173" - Press Fit/Solder - 1/16 - 1/8 0.057 Brass Electro-Tin Vertical
