Non-Insulated
PC Jacks

Filter
09-9004-3-063
09-9004-3-063
09-9004-3-063
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-3-06
09-9004-3-06
09-9004-3-06
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9004-3-04
09-9004-3-04
09-9004-3-04
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9078-1-063
09-9078-1-063
09-9078-1-063
0.040 0.185 " 0.230" - Press Fit/Solder - 1/32 - 1/16 0.0995 (+0.001/-0.003) Brass Bright Tin-Lead Vertical
09-9004-2-063
09-9004-2-063
09-9004-2-063
0.040 0.183 " 0.397" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-2-035
09-9004-2-035
09-9004-2-035
0.040 0.183 " 0.397" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9649-1-063
09-9649-1-063
09-9649-1-063
0.015 - 0.021 0.150 " 0.290" Jack/Pin Press Fit/Solder - 1/16 - 3/32 0.043 Brass Bright Tin-Lead Vertical
09-9744-1-03
09-9744-1-03
09-9744-1-03
0.032 - 0.046 0.300 " 0.800" Jack/Pin Solder - 1/32 - 3/8 0.082 Brass Gold Vertical
09-9262-1-06
09-9262-1-06
09-9262-1-06
0.040 0.220 " 0.375" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.083 Brass Electro-Tin Vertical
09-9262-1-088
09-9262-1-088
09-9262-1-088
0.040 0.220 " 0.375" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.083 Brass Bright Tin-Lead Vertical
09-9262-1-035
09-9262-1-035
09-9262-1-035
0.040 0.220 " 0.375" Jack/Pin Press Fit/Solder - 1/16 - 3/16 0.083 Brass Gold Vertical
09-9001-1-03
09-9001-1-03
09-9001-1-03
0.040 0.190 " 0.206" - Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9642-1-06
09-9642-1-06
09-9642-1-06
0.065 - 0.082 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.096 Brass Electro-Tin Vertical
09-9642-1-04
09-9642-1-04
09-9642-1-04
0.065 - 0.082 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.096 Brass Electro-Tin Vertical
09-9642-1-03
09-9642-1-03
09-9642-1-03
0.065 - 0.082 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.096 Brass Gold Vertical
09-9642-6-063
09-9642-6-063
09-9642-6-063
0.065 - 0.082 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.096 Brass Bright Tin-Lead Vertical
09-9642-6-035
09-9642-6-035
09-9642-6-035
0.065 - 0.082 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.096 Brass Gold Vertical
09-9642-6-03
09-9642-6-03
09-9642-6-03
0.065 - 0.082 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.096 Brass Gold Vertical
09-9642-4-06
09-9642-4-06
09-9642-4-06
0.065 - 0.082 0.375 " 0.699" Jack/Turret Swage Mount 0.156" 1/8 0.096 Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
