Non-Insulated
PC Jacks

Filter
09-9644-1-063
09-9644-1-063
09-9644-1-063
0.040 - 0.060 0.205 " 0.270" - Press Fit/Solder - 3/32 - 3/16 0.106 Brass Bright Tin-Lead Vertical
09-9279-1-035
09-9279-1-035
09-9279-1-035
0.040 0.200 " 0.475" Jack/Turret Press Fit/Solder - 1/16 - 1/8 0.062 Brass Gold Vertical
09-9005-2-03
09-9005-2-03
09-9005-2-03
0.040 0.190 " 0.481" Jack/Pin Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9005-1-088
09-9005-1-088
09-9005-1-088
0.040 0.190 " 0.449" Jack/Pin Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-1-063
09-9005-1-063
09-9005-1-063
0.040 0.190 " 0.449" Jack/Pin Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-1-06
09-9005-1-06
09-9005-1-06
0.040 0.190 " 0.449" Jack/Pin Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9004-6-088
09-9004-6-088
09-9004-6-088
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9237-1-04
09-9237-1-04
09-9237-1-04
0.030 0.110 " 0.424" Jack/Pin Solder - 1/32 - 3/32 0.072 Brass Electro-Tin Vertical
09-9004-6-04
09-9004-6-04
09-9004-6-04
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9650-1-063
09-9650-1-063
09-9650-1-063
0.015 - 0.025 0.205 " 0.248" Jack/Pin Solder - 1/32 - 5/32 0.052 Brass Bright Tin-Lead Vertical
09-9666-1-03
09-9666-1-03
09-9666-1-03
0.015 - 0.025 0.126 " 0.146" - Press Fit/Solder - 1/16 - 3/32 0.057 Brass Gold Vertical
09-9666-1-04
09-9666-1-04
09-9666-1-04
0.015 - 0.025 0.126 " 0.146" - Press Fit/Solder - 1/16 - 3/32 0.057 Brass Electro-Tin Vertical
09-9004-6-035
09-9004-6-035
09-9004-6-035
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9667-1-088
09-9667-1-088
09-9667-1-088
0.015 - 0.025 0.100 " 0.125" - Solder - 1/32 - 1/16 0.0635 Brass Bright Tin-Lead Vertical
09-9004-4-088
09-9004-4-088
09-9004-4-088
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9667-1-03
09-9667-1-03
09-9667-1-03
0.015 - 0.025 0.100 " 0.125" - Solder - 1/32 - 1/16 0.0635 Brass Gold Vertical
09-9661-1-063
09-9661-1-063
09-9661-1-063
0.015 - 0.025 0.120 " 0.180" - Solder - 1/32 - 1/16 0.0635 Brass Bright Tin-Lead Vertical
09-9004-4-063
09-9004-4-063
09-9004-4-063
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-4-035
09-9004-4-035
09-9004-4-035
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
