Insulated
PC Jacks

Filter
1128-20-03515
1128-20-03515
1128-20-03515
0.093 0.455 " 0.761" Jack/Turret Press Fit 0.187 1/32 - 21/64 Vertical - - PTFE Green -
1128-04-030110
1128-04-030110
1128-04-030110
0.040 0.140 " 0.345" Jack/Turret Press Fit 0.127 1/32 - 1/8 Vertical - - PTFE Black -
1128-04-030111
1128-04-030111
1128-04-030111
0.040 0.140 " 0.345" Jack/Turret Press Fit 0.127 1/32 - 1/8 Vertical - - PTFE Brown -
1128-20-03519
1128-20-03519
1128-20-03519
0.093 0.455 " 0.761" Jack/Turret Press Fit 0.187 1/32 - 21/64 Vertical - - PTFE White -
09-9071-1-08812
09-9071-1-08812
09-9071-1-08812
0.061 0.190 " 0.656" - - - - - Brass Bright Tin-Lead Polyolefin Red -
09-9060-1-0314
09-9060-1-0314
09-9060-1-0314
0.080 0.332 " 0.688" Jack/Eyelet Press Fit 0.203 1/32 - 23/64 Vertical Brass Gold PTFE Yellow -
09-9055-1-03515
09-9055-1-03515
09-9055-1-03515
0.025 0.145 " 0.431" Jack/Pin - - - - Brass Gold Polyolefin Green -
1128-07-0316
1128-07-0316
1128-07-0316
0.040 0.078 " 0.203" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Blue -
1128-07-0314
1128-07-0314
1128-07-0314
0.040 0.078 " 0.203" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Yellow -
1128-07-0313
1128-07-0313
1128-07-0313
0.040 0.078 " 0.203" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Orange -
1128-07-0312
1128-07-0312
1128-07-0312
0.040 0.078 " 0.203" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Red -
1128-06-03519
1128-06-03519
1128-06-03519
0.040 0.078 " 0.190" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE White -
1128-06-03516
1128-06-03516
1128-06-03516
0.040 0.078 " 0.190" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Blue -
1128-06-03515
1128-06-03515
1128-06-03515
0.040 0.078 " 0.190" Jack/Turret Press Fit 0.136 1/32 - 1/16 Vertical - - PTFE Green -
09-9092-1-08817
09-9092-1-08817
09-9092-1-08817
0.050 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Violet -
09-9175-1-08816
09-9175-1-08816
09-9175-1-08816
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Blue -
09-9092-1-08818
09-9092-1-08818
09-9092-1-08818
0.050 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Gray -
09-9216-1-0310
09-9216-1-0310
09-9216-1-0310
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Gold PTFE Black -
09-9211-1-03217
09-9211-1-03217
09-9211-1-03217
0.062 0.190 " 0.438" Jack/Turret Press Fit 0.159  1/32 - 3/16 Vertical Brass Gold PTFE Violet -
1138-03-0319
1138-03-0319
1138-03-0319
0.080 0.250 " 0.441" - Swage Mount 0.114 1/32 Vertical - - PTFE White -
