Insulated
PC Jacks

Filter
09-9211-1-03213
09-9211-1-03213
09-9211-1-03213
0.062 0.190 " 0.438" Jack/Turret Press Fit 0.159  1/32 - 3/16 Vertical Brass Gold PTFE Orange -
09-9211-1-03212
09-9211-1-03212
09-9211-1-03212
0.062 0.190 " 0.438" Jack/Turret Press Fit 0.159  1/32 - 3/16 Vertical Brass Gold PTFE Red -
09-9211-1-03211
09-9211-1-03211
09-9211-1-03211
0.062 0.190 " 0.438" Jack/Turret Press Fit 0.159  1/32 - 3/16 Vertical Brass Gold PTFE Brown -
09-9084-1-0311
09-9084-1-0311
09-9084-1-0311
0.080 0.340 " 0.453" Jack/Turret Press Fit 0.172 1/32 - 15/64 Vertical Brass Gold PTFE Brown -
21-9205-1-0315
21-9205-1-0315
21-9205-1-0315
0.080 0.400 " 0.410" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Green -
09-9084-1-0313
09-9084-1-0313
09-9084-1-0313
0.080 0.340 " 0.453" Jack/Turret Press Fit 0.172 1/32 - 15/64 Vertical Brass Gold PTFE Orange -
21-9205-1-03515
21-9205-1-03515
21-9205-1-03515
0.080 0.400 " 0.410" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Green -
09-9208-1-03516
09-9208-1-03516
09-9208-1-03516
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Blue M39024/11-47G
09-9175-1-0319
09-9175-1-0319
09-9175-1-0319
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Gold PTFE White -
09-9208-1-03517
09-9208-1-03517
09-9208-1-03517
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Violet M39024/11-50G
09-9175-1-0612
09-9175-1-0612
09-9175-1-0612
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Red -
09-9208-1-0319
09-9208-1-0319
09-9208-1-0319
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon White -
09-9208-1-0318
09-9208-1-0318
09-9208-1-0318
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Gray -
09-9011-1-03512
09-9011-1-03512
09-9011-1-03512
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.137 1/32 - 3/16 Vertical Brass Gold PTFE Red M39024/12-13
09-9221-1-0311
09-9221-1-0311
09-9221-1-0311
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon Brown -
09-9216-1-04410
09-9216-1-04410
09-9216-1-04410
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Bright Tin-Lead PTFE Black -
09-9216-1-03518
09-9216-1-03518
09-9216-1-03518
0.060 0.250 " 0.287" - Solder 0.102  1/32 - 3/32 Vertical Brass Gold PTFE Gray -
09-9265-1-0319
09-9265-1-0319
09-9265-1-0319
0.040 0.190 " 0.605" Jack/Pin Press Fit 0.172 1/32 - 3/16 Vertical Brass Gold PTFE White -
09-9083-1-0414
09-9083-1-0414
09-9083-1-0414
0.140 0.190 " 0.516" Jack/Pin - - - - Brass Electro-Tin Polyolefin Yellow -
1138-03-0319
1138-03-0319
1138-03-0319
0.080 0.250 " 0.441" - Swage Mount 0.114 1/32 Vertical - - PTFE White -

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
