Military
Non-Insulated
Terminals

Filter
15R-503-2-095
15R-503-2-095
15R-503-2-095
0.432" Double Turret/Double Turret Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Hot Solder Dip M55155/15XC01 AA59126/15XC01
15R-509-2-095
15R-509-2-095
15R-509-2-095
0.751" Double Turret/Double Turret Swage Mount 0.093" 1/16 0.204 Phosphor Bronze Hot Solder Dip M55155/15XC07 AA59126/15XC07
15R-509-3-095
15R-509-3-095
15R-509-3-095
0.783" Double Turret/Double Turret Swage Mount 0.125" 3/32 0.204 Phosphor Bronze Hot Solder Dip M55155/15XC08 AA59126/15XC08
15R-509-2-088
15R-509-2-088
15R-509-2-088
0.751" Double Turret/Double Turret Swage Mount 0.093" 1/16 0.204 Phosphor Bronze Bright Tin-Lead M55155/15XD07 AA59126/15XD07
15R-509-4-05
15R-509-4-05
15R-509-4-05
0.814" Double Turret/Double Turret Swage Mount 0.156" 1/8 0.204 Phosphor Bronze Electro Solder M55155/15XB09 AA59126/15XB09
15R-509-3-05
15R-509-3-05
15R-509-3-05
0.783" Double Turret/Double Turret Swage Mount 0.125" 3/32 0.204 Phosphor Bronze Electro Solder M55155/15XB08 AA59126/15XB08
15R-509-2-05
15R-509-2-05
15R-509-2-05
0.751" Double Turret/Double Turret Swage Mount 0.093" 1/16 0.204 Phosphor Bronze Electro Solder M55155/15XB07 AA59126/15XB07
15R-512-3-088
15R-512-3-088
15R-512-3-088
0.506" Double Turret/Double Turret Swage Mount 0.135" 3/32 0.129 Phosphor Bronze Bright Tin-Lead M55155/15XD05 AA59126/15XD05
15R-512-4-088
15R-512-4-088
15R-512-4-088
0.536" Double Turret/Double Turret Swage Mount 0.165" 1/8 0.129 Phosphor Bronze Bright Tin-Lead M55155/15XD06 AA59126/15XD06
15R-512-2-095
15R-512-2-095
15R-512-2-095
0.476" Double Turret/Double Turret Swage Mount 0.105" 1/16 0.129 Phosphor Bronze Hot Solder Dip M55155/15XC04 AA59126/15XC04
15R-541-4-095
15R-541-4-095
15R-541-4-095
0.634" TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.116 Phosphor Bronze Hot Solder Dip M55155/14XC06 AA59126/14XC06
15R-541-2-095
15R-541-2-095
15R-541-2-095
0.574" TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.116 Phosphor Bronze Hot Solder Dip M55155/14XC04 AA59126/14XC04
15-576-2-05
15-576-2-05
15-576-2-05
0.386" Turret/Turret Swage Mount 0.105" 1/16 0.120 Brass Electro Solder M55155/13XH04 AA59126/13XH04
15R-576-3-095
15R-576-3-095
15R-576-3-095
0.416" Turret/Turret Swage Mount 0.135" 3/32 0.120 Phosphor Bronze Hot Solder Dip M55155/13XC05 AA59126/13XC05
15R-576-3-088
15R-576-3-088
15R-576-3-088
0.416" Turret/Turret Swage Mount 0.135" 3/32 0.120 Phosphor Bronze Bright Tin-Lead M55155/13XD05 AA59126/13XD05
15-576-3-05
15-576-3-05
15-576-3-05
0.416" Turret/Turret Swage Mount 0.135" 3/32 0.120 Brass Electro Solder M55155/13XH05 AA59126/13XH05
15R-576-2-088
15R-576-2-088
15R-576-2-088
0.386" Turret/Turret Swage Mount 0.105" 1/16 0.120 Phosphor Bronze Bright Tin-Lead M55155/13XD04 AA59126/13XD04
15R-576-2-095
15R-576-2-095
15R-576-2-095
0.386" Turret/Turret Swage Mount 0.105" 1/16 0.120 Phosphor Bronze Hot Solder Dip M55155/13XC04 AA59126/13XC04
15R-601-1-088
15R-601-1-088
15R-601-1-088
0.363" - Swage Mount 0.062" 1/32 0.094 Phosphor Bronze Bright Tin-Lead M55155/31XD01 AA59126/31XD01
15R-601-6-05
15R-601-6-05
15R-601-6-05
0.519" - Swage Mount 0.218" 3/16 0.094 Phosphor Bronze Electro Solder M55155/31XB10 AA59126/31XB10
