Military
Non-Insulated
Terminals

Filter
15R-494-2-088
15R-494-2-088
15R-494-2-088
0.209" - Swage Mount 0.084" 1/16 0.043 Phosphor Bronze Bright Tin-Lead M55155/24XD12 AA59126/24XD12
15R-494-4-095
15R-494-4-095
15R-494-4-095
0.272" - Swage Mount 0.147" 1/8 0.043 Phosphor Bronze Hot Solder Dip M55155/24XC14 AA59126/24XC14
15R-494-2-095
15R-494-2-095
15R-494-2-095
0.209" - Swage Mount 0.084" 1/16 0.043 Phosphor Bronze Hot Solder Dip M55155/24XC12 AA59126/24XC12
15R-494-4-05
15R-494-4-05
15R-494-4-05
0.272" - Swage Mount 0.147" 1/8 0.043 Phosphor Bronze Electro Solder M55155/24XB14 AA59126/24XB14
15R-494-2-05
15R-494-2-05
15R-494-2-05
0.209" - Swage Mount 0.084" 1/16 0.043 Phosphor Bronze Electro Solder M55155/24XB12 AA59126/24XB12
15R-494-1-05
15R-494-1-05
15R-494-1-05
0.178" - Swage Mount 0.053" 1/32 0.043 Phosphor Bronze Electro Solder M55155/24XB11 AA59126/24XB11
15R-501-3-05
15R-501-3-05
15R-501-3-05
0.299" Turret/Turret Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Electro Solder M55155/13XB02 AA59126/13XB02
15R-501-2-05
15R-501-2-05
15R-501-2-05
0.268" Turret/Turret Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Electro Solder M55155/13XB01 AA59126/13XB01
15R-501-3-088
15R-501-3-088
15R-501-3-088
0.299" Turret/Turret Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Bright Tin-Lead M55155/13XD02 AA59126/13XD02
15R-501-4-088
15R-501-4-088
15R-501-4-088
0.331" Turret/Turret Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Bright Tin-Lead M55155/13XD03 AA59126/13XD03
15R-501-3-095
15R-501-3-095
15R-501-3-095
0.299" Turret/Turret Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Hot Solder Dip M55155/13XC02 AA59126/13XC02
15R-501-2-095
15R-501-2-095
15R-501-2-095
0.268" Turret/Turret Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Hot Solder Dip M55155/13XC01 AA59126/13XC01
15R-501-4-05
15R-501-4-05
15R-501-4-05
0.331" Turret/Turret Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Electro Solder M55155/13XB03 AA59126/13XB03
15R-502-2-05
15R-502-2-05
15R-502-2-05
0.350" TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Electro Solder M55155/14XB01 AA59126/14XB01
15R-502-3-088
15R-502-3-088
15R-502-3-088
0.381" TURRET/DOUBLE TURRET Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Bright Tin-Lead M55155/14XD02 AA59126/14XD02
15R-502-3-05
15R-502-3-05
15R-502-3-05
0.381" TURRET/DOUBLE TURRET Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Electro Solder M55155/14XB02 AA59126/14XB02
15R-503-4-05
15R-503-4-05
15R-503-4-05
0.495" Double Turret/Double Turret Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Electro Solder M55155/15XB03 AA59126/15XB03
15R-503-3-095
15R-503-3-095
15R-503-3-095
0.463" Double Turret/Double Turret Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Hot Solder Dip M55155/15XC02 AA59126/15XC02
15R-503-3-05
15R-503-3-05
15R-503-3-05
0.463" Double Turret/Double Turret Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Electro Solder M55155/15XB02 AA59126/15XB02
15R-503-2-088
15R-503-2-088
15R-503-2-088
0.432" Double Turret/Double Turret Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Bright Tin-Lead M55155/15XD01 AA59126/15XD01
