Military
Non-Insulated
Terminals

Filter
15-509-2-088
15-509-2-088
15-509-2-088
0.751" Double Turret/Double Turret Swage Mount 0.093" 1/16 0.204 Brass Bright Tin-Lead M55155/15XJ07 AA59126/15XJ07
15R-270-1-05
15R-270-1-05
15R-270-1-05
0.437" - Swage Mount 0.078" 1/32 0.116 Phosphor Bronze Electro Solder M55155/30XB04 AA59126/30XB04
15R-270-2-05
15R-270-2-05
15R-270-2-05
0.468" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Electro Solder M55155/30XB07 AA59126/30XB07
15R-270-3-088
15R-270-3-088
15R-270-3-088
0.499" - Swage Mount 0.140" 3/32 0.116 Phosphor Bronze Bright Tin-Lead M55155/30XD11 AA59126/30XD11
15R-270-4-088
15R-270-4-088
15R-270-4-088
0.530" - Swage Mount 0.171" 1/8 0.116 Phosphor Bronze Bright Tin-Lead M55155/30XD15 AA59126/30XD15
15R-270-6-088
15R-270-6-088
15R-270-6-088
0.593" - Swage Mount 0.234" 3/16 0.116 Phosphor Bronze Bright Tin-Lead M55155/30XD18 AA59126/30XD18
15R-270-8-088
15R-270-8-088
15R-270-8-088
0.657" - Swage Mount 0.298" 1/4 0.116 Phosphor Bronze Bright Tin-Lead M55155/30XD21 AA59126/30XD21
15R-270-4-095
15R-270-4-095
15R-270-4-095
0.530" - Swage Mount 0.171" 1/8 0.116 Phosphor Bronze Hot Solder Dip M55155/30XC15 AA59126/30XC15
15R-270-3-095
15R-270-3-095
15R-270-3-095
0.499" - Swage Mount 0.140" 3/32 0.116 Phosphor Bronze Hot Solder Dip M55155/30XC11 AA59126/30XC11
15R-302-4-05
15R-302-4-05
15R-302-4-05
0.303" - Swage Mount 0.147" 1/8 0.067 Phosphor Bronze Electro Solder M55155/16XB03 AA59126/16XB03
15R-302-3-05
15R-302-3-05
15R-302-3-05
0.271" - Swage Mount 0.115" 3/32 0.067 Phosphor Bronze Electro Solder M55155/16XB02 AA59126/16XB02
15R-302-2-05
15R-302-2-05
15R-302-2-05
0.240" - Swage Mount 0.084" 1/16 0.067 Phosphor Bronze Electro Solder M55155/16XB01 AA59126/16XB01
15R-302-4-095
15R-302-4-095
15R-302-4-095
0.303" - Swage Mount 0.147" 1/8 0.067 Phosphor Bronze Hot Solder Dip M55155/16XC03 AA59126/16XC03
15R-302-3-095
15R-302-3-095
15R-302-3-095
0.271" - Swage Mount 0.115" 3/32 0.067 Phosphor Bronze Hot Solder Dip M55155/16XC02 AA59126/16XC02
15R-302-4-088
15R-302-4-088
15R-302-4-088
0.303" - Swage Mount 0.147" 1/8 0.067 Phosphor Bronze Bright Tin-Lead M55155/16XD03 AA59126/16XD03
15R-302-2-095
15R-302-2-095
15R-302-2-095
0.240" - Swage Mount 0.084" 1/16 0.067 Phosphor Bronze Hot Solder Dip M55155/16XC01 AA59126/16XC01
15R-349-4-095
15R-349-4-095
15R-349-4-095
0.500" - Swage Mount 0.172" 1/8 0.116 Phosphor Bronze Hot Solder Dip M55155/17XC03 AA59126/17XC03
15R-349-3-095
15R-349-3-095
15R-349-3-095
0.469" - Swage Mount 0.141" 3/32 0.116 Phosphor Bronze Hot Solder Dip M55155/17XC02 AA59126/17XC02
15R-349-2-05
15R-349-2-05
15R-349-2-05
0.437" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Electro Solder M55155/17XB01 AA59126/17XB01
15R-349-2-088
15R-349-2-088
15R-349-2-088
0.437" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Bright Tin-Lead M55155/17XD01 AA59126/17XD01
