Military
Non-Insulated
Terminals

Filter
15-501-2-088
15-501-2-088
15-501-2-088
0.268" Turret/Turret Swage Mount 0.082" 1/16 0.076 Brass Bright Tin-Lead M55155/13XJ01 AA59126/13XJ01
15-501-3-095
15-501-3-095
15-501-3-095
0.299" Turret/Turret Swage Mount 0.113" 3/32 0.076 Brass Hot Solder Dip M55155/13XI02 AA59126/13XI02
15-576-4-088
15-576-4-088
15-576-4-088
0.446" Turret/Turret Swage Mount 0.165" 1/8 0.120 Brass Bright Tin-Lead M55155/13XJ06 AA59126/13XJ06
15-501-4-05
15-501-4-05
15-501-4-05
0.331" Turret/Turret Swage Mount 0.145" 1/8 0.076 Brass Electro Solder M55155/13XH03 AA59126/13XH03
15-501-2-05
15-501-2-05
15-501-2-05
0.268" Turret/Turret Swage Mount 0.082" 1/16 0.076 Brass Electro Solder M55155/13XH01 AA59126/13XH01
15-501-3-05
15-501-3-05
15-501-3-05
0.299" Turret/Turret Swage Mount 0.113" 3/32 0.076 Brass Electro Solder M55155/13XH02 AA59126/13XH02
15R-576-4-088
15R-576-4-088
15R-576-4-088
0.446" Turret/Turret Swage Mount 0.165" 1/8 0.120 Phosphor Bronze Bright Tin-Lead M55155/13XD06 AA59126/13XD06
15-541-2-095
15-541-2-095
15-541-2-095
0.574" TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.116 Brass Hot Solder Dip M55155/14XI04 AA59126/14XI04
15-541-3-05
15-541-3-05
15-541-3-05
0.604" TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.116 Brass Electro Solder M55155/14XH05 AA59126/14XH05
15-502-2-05
15-502-2-05
15-502-2-05
0.350" TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.076 Brass Electro Solder M55155/14XH01 AA59126/14XH01
15-502-4-088
15-502-4-088
15-502-4-088
0.413" TURRET/DOUBLE TURRET Swage Mount 0.145" 1/8 0.076 Brass Bright Tin-Lead M55155/14XJ03 AA59126/14XJ03
15-541-3-088
15-541-3-088
15-541-3-088
0.604" TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.116 Brass Bright Tin-Lead M55155/14XJ05 AA59126/14XJ05
15-541-4-095
15-541-4-095
15-541-4-095
0.634" TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.116 Brass Hot Solder Dip M55155/14XI06 AA59126/14XI06
15-509-3-095
15-509-3-095
15-509-3-095
0.783" Double Turret/Double Turret Swage Mount 0.125" 3/32 0.204 Brass Hot Solder Dip M55155/15XI08 AA59126/15XI08
15-509-3-088
15-509-3-088
15-509-3-088
0.783" Double Turret/Double Turret Swage Mount 0.125" 3/32 0.204 Brass Bright Tin-Lead M55155/15XJ08 AA59126/15XJ08
15-509-4-088
15-509-4-088
15-509-4-088
0.814" Double Turret/Double Turret Swage Mount 0.156" 1/8 0.204 Brass Bright Tin-Lead M55155/15XJ09 AA59126/15XJ09
15-512-4-05
15-512-4-05
15-512-4-05
0.536" Double Turret/Double Turret Swage Mount 0.165" 1/8 0.129 Brass Electro Solder M55155/15XH06 AA59126/15XH06
15-503-4-095
15-503-4-095
15-503-4-095
0.495" Double Turret/Double Turret Swage Mount 0.145" 1/8 0.076 Brass Hot Solder Dip M55155/15XI03 AA59126/15XI03
15-503-4-05
15-503-4-05
15-503-4-05
0.495" Double Turret/Double Turret Swage Mount 0.145" 1/8 0.076 Brass Electro Solder M55155/15XH03 AA59126/15XH03
15-141-3-095
15-141-3-095
15-141-3-095
0.209" - Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip M55155/11XI06 AA59126/11XI06
