Military
Insulated
Terminals

Filter
1169-36M-09512Z
1169-36M-09512Z
1169-36M-09512Z
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Red M55155/092C03 AA59126/092C03
1127-69M-0518Z
1127-69M-0518Z
1127-69M-0518Z
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Gray M55155/188B02 AA59126/188B02
1100-07M-08812Z
1100-07M-08812Z
1100-07M-08812Z
0.350" - Press Fit 1/16 0.086 PTFE Red M55155/082D02 AA59126/082D02
1127-68M-09519Z
1127-68M-09519Z
1127-68M-09519Z
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE White M55155/189C01 AA59126/189C01
1125-45M-09517Z
1125-45M-09517Z
1125-45M-09517Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Violet M55155/097C02 AA59126/097C02
1127-68M-08813Z
1127-68M-08813Z
1127-68M-08813Z
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Orange M55155/183D01 AA59126/183D01
1100-07M-08815Z
1100-07M-08815Z
1100-07M-08815Z
0.350" - Press Fit 1/16 0.086 PTFE Green M55155/085D02 AA59126/085D02
1169-36M-09517Z
1169-36M-09517Z
1169-36M-09517Z
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Violet M55155/097C03 AA59126/097C03
1127-69M-0517Z
1127-69M-0517Z
1127-69M-0517Z
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Violet M55155/187B02 AA59126/187B02
1125-45M-09515Z
1125-45M-09515Z
1125-45M-09515Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Green M55155/095C02 AA59126/095C02
1100-07M-0512Z
1100-07M-0512Z
1100-07M-0512Z
0.350" - Press Fit 1/16 0.086 PTFE Red M55155/082B02 AA59126/082B02
1102-14M-09513Z
1102-14M-09513Z
1102-14M-09513Z
0.359" - Press Fit 1/16 0.136 PTFE Orange M55155/073C01 AA59126/073C01
1127-68M-09514Z
1127-68M-09514Z
1127-68M-09514Z
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Yellow M55155/184C01 AA59126/184C01
1127-68M-09512Z
1127-68M-09512Z
1127-68M-09512Z
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Red M55155/182C01 AA59126/182C01
1127-69M-09519Z
1127-69M-09519Z
1127-69M-09519Z
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE White M55155/189C02 AA59126/189C02
1127-68M-0510Z
1127-68M-0510Z
1127-68M-0510Z
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Black M55155/180B01 AA59126/180B01
1110-21M-0510Z
1110-21M-0510Z
1110-21M-0510Z
0.515" Pin/Pin Press Fit 1/16 0.136 PTFE Black M55155/030B02 AA59126/030B02
1127-69M-09517Z
1127-69M-09517Z
1127-69M-09517Z
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Violet M55155/187C02 AA59126/187C02
1127-69M-0516Z
1127-69M-0516Z
1127-69M-0516Z
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Blue M55155/186B02 AA59126/186B02
1100-07M-08817Z
1100-07M-08817Z
1100-07M-08817Z
0.350" - Press Fit 1/16 0.086 PTFE Violet M55155/087D02 AA59126/087D02
