Military
Insulated
Terminals

Filter
1127-05M-09516Z
1127-05M-09516Z
1127-05M-09516Z
0.937" - 4-40 Screw - CLEARANCE FOR Screw #4 DIALLYL PHTHALATE Blue M55155/206C02 AA59126/206C02
1127-07M-09514Z
1127-07M-09514Z
1127-07M-09514Z
0.937" - 6-32 Screw - CLEARANCE FOR Screw #6 DIALLYL PHTHALATE Yellow M55155/204C04 AA59126/204C04
1125-43M-09513Z
1125-43M-09513Z
1125-43M-09513Z
0.750" - 4-40 Nut 1/8 0.120 PTFE Orange M55155/093C01 AA59126/093C01
1125-43M-09514Z
1125-43M-09514Z
1125-43M-09514Z
0.750" - 4-40 Nut 1/8 0.120 PTFE Yellow M55155/094C01 AA59126/094C01
1127-06M-09516Z
1127-06M-09516Z
1127-06M-09516Z
0.390" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Blue M55155/206C03 AA59126/206C03
1169-37M-09516Z
1169-37M-09516Z
1169-37M-09516Z
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE Blue M55155/096C04 AA59126/096C04
1169-37M-09514Z
1169-37M-09514Z
1169-37M-09514Z
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE Yellow M55155/094C04 AA59126/094C04
1102-14M-08817Z
1102-14M-08817Z
1102-14M-08817Z
0.359" - Press Fit 1/16 0.136 PTFE Violet M55155/077D01 AA59126/077D01
1125-45M-08814Z
1125-45M-08814Z
1125-45M-08814Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Yellow M55155/094D02 AA59126/094D02
1125-45M-08815Z
1125-45M-08815Z
1125-45M-08815Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Green M55155/095D02 AA59126/095D02
1169-37M-09517Z
1169-37M-09517Z
1169-37M-09517Z
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE Violet M55155/097C04 AA59126/097C04
1125-45M-08816Z
1125-45M-08816Z
1125-45M-08816Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Blue M55155/096D02 AA59126/096D02
1117-01M-0516Z
1117-01M-0516Z
1117-01M-0516Z
0.690" TURRET/PIN 12-28 Nut 3/32 0.221 PTFE Blue M55155/026B01 AA59126/026B01
1125-43M-08812Z
1125-43M-08812Z
1125-43M-08812Z
0.750" - 4-40 Nut 1/8 0.120 PTFE Red M55155/092D01 AA59126/092D01
1117-01M-08812Z
1117-01M-08812Z
1117-01M-08812Z
0.690" TURRET/PIN 12-28 Nut 3/32 0.221 PTFE Red M55155/022D01 AA59126/022D01
1125-45M-08817Z
1125-45M-08817Z
1125-45M-08817Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Violet M55155/097D02 AA59126/097D02
1125-45M-08819Z
1125-45M-08819Z
1125-45M-08819Z
0.890" - 6-32 Nut 1/8 0.144 PTFE White M55155/099D02 AA59126/099D02
1169-37M-09518Z
1169-37M-09518Z
1169-37M-09518Z
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE Gray M55155/098C04 AA59126/098C04
1125-45M-08811Z
1125-45M-08811Z
1125-45M-08811Z
0.890" - 6-32 Nut 1/8 0.144 PTFE Brown M55155/091D02 AA59126/091D02
1169-36M-0513Z
1169-36M-0513Z
1169-36M-0513Z
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Orange M55155/093B03 AA59126/093B03
