Commercial
Non-Insulated
Terminals

Filter
10-204-3-044
10-204-3-044
10-204-3-044
0.500" - - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin YES
10-117-2-044
10-117-2-044
10-117-2-044
0.178" - - Swage Mount 0.084" 1/16 0.067 Brass Bright Tin YES
09-8422-2-044
09-8422-2-044
09-8422-2-044
0.245" - - Swage Mount 0.094" 1/16 0.067 Brass Bright Tin YES
10-117-4-044
10-117-4-044
10-117-4-044
0.241" - - Swage Mount 0.147" 1/8 0.067 Brass Bright Tin YES
09-0272-1-044
09-0272-1-044
09-0272-1-044
0.243" - - Swage Mount 0.055" 1/32 0.067 Brass Bright Tin YES
09-8842-1-044
09-8842-1-044
09-8842-1-044
0.450" 0.040 - - - - - Brass Bright Tin YES
10-525-1-044
10-525-1-044
10-525-1-044
0.489" - Double Turret/Double Turret Swage Mount 0.053" 1/32 0.094 Brass Bright Tin YES
09-8809-2-044
09-8809-2-044
09-8809-2-044
0.269" 0.030 - Swage Mount 0.084" 1/16 0.096 Brass Bright Tin YES
09-0302-1-044
09-0302-1-044
09-0302-1-044
0.225" - - Swage Mount 0.075" 1/16 0.094 Brass Bright Tin YES
10-449-1-044
10-449-1-044
10-449-1-044
0.209" - - Swage Mount 0.053" 1/32 0.064 Brass Bright Tin YES
09-8174-1-044
09-8174-1-044
09-8174-1-044
0.951" 0.025 (+0.000/-0.005) - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
09-0011-2-044
09-0011-2-044
09-0011-2-044
0.417" - - Swage Mount 0.105" 1/16 0.116 Brass Bright Tin YES
09-0144-2-044
09-0144-2-044
09-0144-2-044
0.588" - - 8-32 - - 8-32 THREAD Brass Bright Tin YES
10-8008-4-044
10-8008-4-044
10-8008-4-044
0.556" 0.080 - Swage Mount 0.156" 1/8 0.094 Brass Bright Tin YES
09-8158-2-044
09-8158-2-044
09-8158-2-044
0.757" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Bright Tin YES
09-8157-2-044
09-8157-2-044
09-8157-2-044
0.540" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Bright Tin YES
10-532-4-044
10-532-4-044
10-532-4-044
0.633" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.159 Brass Bright Tin YES
09-0257-1-044
09-0257-1-044
09-0257-1-044
0.346" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Bright Tin YES
10-550-3-044
10-550-3-044
10-550-3-044
0.604" - TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.206 Brass Bright Tin YES
10-802-2-044
10-802-2-044
10-802-2-044
0.302" 0.032 TURRET/PIN Swage Mount 0.084" 1/16 0.067 Brass Bright Tin YES

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
