Commercial
Non-Insulated
Terminals

Filter
10-801-8-044
10-801-8-044
10-801-8-044
0.598" 0.040 TURRET/PIN Swage Mount 0.270" 1/4 0.076 Brass Bright Tin YES
09-8706-1-044
09-8706-1-044
09-8706-1-044
0.281" 0.050 - Press Fit/Solder 0.075" 1/16 0.086 Brass Bright Tin YES
09-8117-2-044
09-8117-2-044
09-8117-2-044
0.532" 0.041 DOUBLE TURRET/PIN Swage Mount 0.094" 1/16 0.119 Brass Bright Tin YES
10-443-4-04
10-443-4-04
10-443-4-04
0.411" - SLOTTED/TURRET Swage Mount 0.156" 1/8 0.125 Brass Electro-Tin YES
10-803-1-044
10-803-1-044
10-803-1-044
0.426" 0.040 TURRET/PIN Swage Mount 0.051" 1/32 0.076 Brass Bright Tin YES
10-309-2-04
10-309-2-04
10-309-2-04
0.422" - - Swage Mount 0.105" 1/16 0.116 Brass Electro-Tin YES
10-543-1-044
10-543-1-044
10-543-1-044
0.507" - Double Turret/Double Turret Swage Mount 0.062" 1/32 0.094 Brass Bright Tin YES
10-508-4A-044
10-508-4A-044
10-508-4A-044
0.609" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.206 Brass Bright Tin YES
09-0194-1-044
09-0194-1-044
09-0194-1-044
0.602" 0.040 (+0.000/-0.005) Pin/Pin Swage Mount 0.060" 1/32 0.076 Brass Bright Tin YES
10-605-2-04
10-605-2-04
10-605-2-04
0.445" - - Swage Mount 0.105" 1/16 0.090 Brass Electro-Tin YES
10-330-2A-04
10-330-2A-04
10-330-2A-04
0.312" - - Swage Mount 0.094" 1/16 0.086 Brass Electro-Tin YES
10-331-4-04
10-331-4-04
10-331-4-04
0.500" - - Swage Mount 0.172" 1/8 0.086 Brass Electro-Tin YES
10-526-2-044
10-526-2-044
10-526-2-044
0.625" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Bright Tin YES
10-418-3-044
10-418-3-044
10-418-3-044
0.666" - Turret/Turret Swage Mount 0.135" 3/32 0.120 Brass Bright Tin YES
10-410-4-04
10-410-4-04
10-410-4-04
0.493" - - Swage Mount 0.165" 1/8 0.116 Brass Electro-Tin YES
10-217-2-04
10-217-2-04
10-217-2-04
0.449" - - Swage Mount 0.105" 1/16 0.116 Brass Electro-Tin YES
10-217-5-04
10-217-5-04
10-217-5-04
0.539" - - Swage Mount 0.195" 5/32 0.116 Brass Electro-Tin YES
10-904-1-04
10-904-1-04
10-904-1-04
0.198" - - Swage Mount 0.062" 1/32 0.0635 Brass Electro-Tin YES
10-417-4-04
10-417-4-04
10-417-4-04
0.563" - - Swage Mount 0.172" 1/8 0.116 Brass Electro-Tin YES
09-8687-2-04
09-8687-2-04
09-8687-2-04
0.590" 0.040 Pin/Pin Swage Mount 0.090" 1/16 0.140 Brass Electro-Tin YES
