Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
09-0221-2-05	0.349"	-	-	Swage Mount	0.084"	1/16	0.063	Brass	Electro Solder	NO
09-0219-3-03	0.425"	-	-	Swage Mount	0.115"	3/32	0.067	Brass	Gold	YES
09-0219-3-035	0.425"	-	-	Swage Mount	0.115"	3/32	0.067	Brass	Gold	YES
09-0219-2-03	0.395"	-	-	Swage Mount	0.085"	1/16	0.067	Brass	Gold	YES
09-0212-2-01	0.270"	-	-	Swage Mount	0.084"	1/16	0.076	Brass	Silver	YES
09-0210-6-035	0.260"	-	-	2-56	-	-	2-56 THREAD	Brass	Gold	YES
09-0210-6-044	0.260"	-	-	2-56	-	-	2-56 THREAD	Brass	Bright Tin	YES
09-0210-5-01	0.330"	-	-	2-56	-	-	2-56 THREAD	Brass	Silver	YES
09-0210-5-05	0.330"	-	-	2-56	-	-	2-56 THREAD	Brass	Electro Solder	NO
09-0210-6-03	0.260"	-	-	2-56	-	-	2-56 THREAD	Brass	Gold	YES
09-0210-5-04	0.330"	-	-	2-56	-	-	2-56 THREAD	Brass	Electro-Tin	YES
09-0209-2-01	0.264"	-	-	Swage Mount	0.084"	1/16	0.041	Brass	Silver	YES
09-0209-2-03	0.264"	-	-	Swage Mount	0.084"	1/16	0.041	Brass	Gold	YES
09-0209-2-035	0.264"	-	-	Swage Mount	0.084"	1/16	0.041	Brass	Gold	YES
09-0208-1-095	0.235"	-	-	Swage Mount	0.062"	1/32	0.067	LEADED Red Brass	Hot Solder Dip	NO
09-0208-3-04	0.298"	-	-	Swage Mount	0.125"	3/32	0.067	LEADED Red Brass	Electro-Tin	YES
09-0208-1-05	0.235"	-	-	Swage Mount	0.062"	1/32	0.067	LEADED Red Brass	Electro Solder	NO
09-0208-2-088	0.267"	-	-	Swage Mount	0.094"	1/16	0.067	LEADED Red Brass	Bright Tin-Lead	NO
09-0206-1-03	0.350"	-	-	Solder	-	-	-	Brass	Gold	YES
10-823-2-05	0.564"	0.037 (TAPER)	DOUBLE TURRET/TAPER PIN	Swage Mount	0.087"	1/16	0.120	Brass	Electro Solder	NO
